Decklid Contacts The Body Side Aperture Above The Stop Lamp – 2016 Dodge Charger

NUMBER: 23-049-15
GROUP: Body
DATE: December 08, 2015



THIS SERVICE BULLETIN IS ALSO BEING RELEASED AS RAPID RESPONSE TRANSMITTAL (RRT) 15-119. ALL APPLICABLE SOLD AND UN-SOLD RRT VIN’s HAVE BEEN LOADED. TO VERIFY THAT THIS RRT SERVICE ACTION IS APPLICABLE TO THE VEHICLE, USE VIP OR PERFORM A VIN SEARCH IN TECHCONNECT. ALL REPAIRS ARE REIMBURSABLE WITHIN THE PROVISIONS OF WARRANTY.



SUBJECT:

Decklid Contacts The Body Side Aperture Above The Stop Lamp



OVERVIEW:

This bulletin involves adjusting the decklid and touching up paint as required.



MODELS:

2016

(LD)

Dodge Charger



NOTE: This bulletin applies to vehicles built on or after October 02, 2015 (MDH 1002XX) and on or before October 21, 2015 (MDH 1021XX).



SYMPTOM/CONDITION:

The customer may describe contact between the decklid and body side aperture (1) and/or chipped paint (2) on left or right side above the stop lamp (Fig. 1).

Fig. 1 Contact Areas And Chipped Paint

1 – Decklid To Body Side Aperture Contact
2 – Chipped Paint



DIAGNOSIS:

If a customer’s VIN is listed in VIP or your RRT VIN list, perform the repair. For all other customers that describe the symptom/condition, perform the Repair Procedure.



PARTS REQUIRED:

Qty.	Description	Part No.
1 (AR)	PS2 Bright Silver	04889427AB
1 (AR)	PQD B5 Blue	05163212AA
1 (AR)	PHG Plum Crazy	05163160AA
1 (AR)	PAR Maximum Steel	68154430AA
1 (AR)	PX8 Pitch Black	04342250AB
1 (AR)	PW7 Bright White Clear Coat	04889598AB
1 (AR)	PAU Granite Crystal Met. Clear Coat	68183829AA
1 (AR)	PBX Jazz Blue Pearl Coat	68183807AA
1 (AR)	PSC Billet Silver Metallic Clear Coat	05163738AA
1 (AR)	PR3 TorRed	05163108AA
1 (AR)	PRY Redline Red Tri-Coat Pearl	05163750AA
1 (AR)	PWD Ivory Tri-Coat Pearl	05163838AA



NOTE: Each bottle of touch-up paint will service several vehicles (shop supply).



SPECIAL TOOLS/EQUIPMENT REQUIRED:

2022300230

Gauge, Non-Metallic, Clearance Measurement or equivalent non-metallic clearance gauge.



NOTE: The Non-Metallic Clearance Gauge is a non-reimbursable shop tool.



REPAIR PROCEDURE:

1. Use a 1.75 mm plastic feeler gauge or equivalent to measure the gap (1) between the decklid and body side aperture at the points identified in (Fig. 2). The 1.75 mm feeler gauge should slide freely between the decklid and body side aperture without binding or being unable to pass.

Fig. 2 Measure Decklid To Body Side Aperture Gap

1 – Gap Between Gauge And Fender

---

2. Did the 1.75 mm feeler gauge pass freely between the decklid and body side aperture without binding, indicating the gap is at least 1.75 mm or greater?
   • YES>>> This bulletin has been completed, use LOP (23-00-05-93) to close the active RRT.
   • NO>>> Continue with Step #3.
3. Open the decklid.
4. Open the load floor.
5. Pull forward at the bottom of the trunk trim panel (1) to release the lower retaining clips (Fig. 3).
6. Lift the trunk trim panel (1) up to release the upper retaining clips and remove the panel (Fig. 3).

Fig. 3 Remove Trunk Trim Panel

1 – Trunk Trim Panel

---

7. Using a marking pen or equivalent, mark the decklid striker’s current position (1) (Fig. 4).

8. Loosen the two striker fasteners (2) (Fig. 4).
9. Position the striker (3) approximately 1 mm higher; then tighten the fasteners (2) to 8 N·m (52 in. lbs.) (Fig. 4).

Fig. 4 Adjust Decklid Striker

1 – Mark Striker Current Position
2 – Striker Fasteners
3 – Decklid Striker

---

10. After adjusting the striker, ensure the striker does not rub on the decklid latch. Reposition the striker if necessary.
11. Check the decklid to body side aperture gaps/flushness measurements and closing effort. Decklid to body side aperture gap should be 1.75 mm or greater as measured in Step #1 and decklid should be no more than 1.0 mm over flush in relation to the body side aperture.
12. Did adjusting the decklid striker increase the decklid to body side aperture gap to 1.75 mm or greater without exceeding 1.0 mm overflush of decklid in relation to body side aperture?
    • YES>>> Proceed to Step #22.
    • NO>>> Continue with Step #13.
13. Remove the push fasteners (1) and the decklid hinge cover (2) (Fig. 5).

Fig. 5 Remove Hinge Covers

1 – Push Fasteners
2 – Hinge Cover

---

14. Loosen the two hinge bolts (1) (Fig. 6).
15. Grasp the decklid with both hands and firmly push up (2) (decklid moves rearward) (Fig. 6).

16. Tighten the two hinge bolts (1) to 14 N·m (10 ft. lbs.) (Fig. 6).

Fig. 6 Adjust Decklid

1 – Hinge Bolts
2 – Move Decklid

---

17. Check that the decklid to body side aperture gap is 1.75 mm or greater as measured in Step #1 and is no more than 1.0 mm over flush in relation to the body side aperture. Re-adjust decklid and striker as necessary to achieve the desired fit and spacing between the decklid and body side aperture.
18. Install the decklid hinge cover (2) and push fasteners (1) (Fig. 7).

Fig. 7 Install Hinge Covers

1 – Push Fasteners
2 – Hinge Cover

---

19. Position the top of the trunk trim panel (1) and push down to engage the top retaining clips (Fig. 8).
20. Hand tap the lower edge of the trunk trim panel (1) to engage the lower retaining clips (Fig. 8).

21. Close the load floor cover.

Fig. 8 Install Trunk Trim Panel

1 – Trunk Trim Panel

---

22. If paint was chipped due to contact between the decklid and body side aperture, touch up the paint as required.

Fig. 9 Touch Up Paint Chips

1 – Paint Chips

---

POLICY:

Reimbursable within the provisions of the warranty.



TIME ALLOWANCE:

Labor Operation No:	Description	Skill Category	Amount
23-00-05-93	Inspect Decklid To Body Side Aperture Gap (0 – Introductory)	6 – Electrical and Body Systems	0.2 Hrs.
23-00-05-94	Inspect And Adjust Decklid To Body Side Aperture Gap And Touch Up Paint (0 – Introductory)	6 – Electrical and Body Systems	0.3 Hrs.



FAILURE CODE:

ZZ	Service Action



---

23-049-15



---
