August 29, 2019 NHTSA CAMPAIGN NUMBER: 19V637000

Steering Rack Gear May Fail

A loss of steering control increases the risk of a crash.



NHTSA Campaign Number: 19V637

Manufacturer Chrysler (FCA US LLC)

Components STEERING

Potential Number of Units Affected 5,294



Summary

Chrysler (FCA US LLC) is recalling certain 2019-2020 Jeep Cherokee vehicles. The steering rack gear may break, possibly causing a loss of steering control.



Remedy

Chrysler will notify owners, and dealers will replace the steering gear, free of charge. The recall began October 24, 2019. Owners may contact Chrysler customer service at 1-800-853-1403. Chrysler’s number for this recall is V99.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Vehicle has a Recall




Revised October 2019

Dealer Service Instructions for:

Safety Recall V99 / NHTSA 19V-637 Steering Gear

NOTE: Page 65 revised Step 10.



Remedy Available

2019-2020 (KL) Jeep Cherokee



NOTE:  Some vehicles above may have been identified as not involved in this recall and therefore have been excluded from this recall.



IMPORTANT:  Some of the involved vehicles may be in dealer new vehicle inventory.  Federal law requires you to complete this recall service on these vehicles before retail delivery.  Dealers should also consider this requirement to apply to used vehicle inventory and should perform this recall on vehicles in for service.  Involved vehicles can be determined by using the VIP inquiry process.



Subject

The steering gear on about 5,290 of the above vehicles may have been built with a servo pinion hardness below specification. This could potentially result in a fracture and allow a metal shard to become lodged within the teeth of the steering rack. If this occurs, it can result in a loss of steering control which can cause a vehicle crash without prior warning.



Repair

Replace the steering gear.



Alternate Transportation

Dealers should attempt to minimize customer inconvenience by placing the owner in a loaner vehicle if the vehicle must be held overnight.



Parts Information

All Vehicles

Quantity Description Part Number
1 Steering Gear 68284077AH
2 Bolt, Steering Gear 06512252AA
2 Nut, Steering Gear 06104719AA Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
2 Nut, Tie Rod End Outer 06511905AA
2 Nut, Ball Joint Lower 06507676AA Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
4 Rivet, Front Wheelhouse to Fascia 06510520AA
1 Bolt, Steering Column Intermediate 06510740AA



All Wheel Drive (AWD) / Four Wheel Drive (4WD) vehicles ONLY

Quantity Description Part Number
1 Snap Ring, Propeller Shaft 68224126AA Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
3 Bolts and Retainer, Propeller Shaft 68242709AA



2.0L Engine sales code EC1 (4-cylinder gas)

Quantity Description Part Number
1 Gasket, Exhaust 68239839AA
2 Nut, Exhaust 06104709AA



2.4L Engine sales code EDD/EDE (4-cylinder gas)

Quantity Description Part Number
1 Gasket, Exhaust 68081823AD Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
2 Nut, Exhaust 06104709AA



3.2L Engine sales code EHK (6-cylinder gas)

Quantity Description Part Number
1 Gasket, Exhaust 52022294AA Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
1 Gasket, Exhaust 04880235AC Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
1 Gasket, Exhaust 68110431AB Safety Recall V99 - Steering Gear - 2019-2020 Jeep Cherokee | small light
7 Nut, Exhaust 06104709AA



Return the steering gear to the Mopar Core Return Center for core credit.



Special Tools

The following special tools are required to perform this repair:

  • NPN
wiTECH micro pod II
  • NPN
Laptop Computer
  • NPN
wiTECH Software
  • NPN
Steering Wheel Holder
  • NPN
Wheel Alignment Equipment
  • C-4150A
Ball Joint Press
  • C-3894-A
Tie Rod Puller



Service Procedure



A. Steering Gear Removal



  1. Position the vehicle on a suitable lift.



  1. Place the ignition in the OFF position.



  1. Using a steering wheel holder, lock the steering wheel at the 12 o’clock center position to keep it from rotating. This keeps the clockspring in the proper orientation(Figure 1).



  1. Open the hood.



  1. Disconnect the Intelligent Battery Sensor (IBS) wire   harness connector (Figure 2).



  1. Remove the ground terminal M8 hex nut. Position and secure the ground cable eyelet away from the battery terminal (Figure 2).



  1. Remove intermediate shaft pinch bolt and separate the intermediate shaft from the steering gear pinion shaft. DISCARD the pinch bolt, it is not to be reused (Figure 3).



  1. Front Wheel Drive (FWD) vehicles, proceed to Step 9.

All Wheel Drive (AWD) / Four Wheel Drive (4WD) vehicles, place the transmission in NEUTRAL following steps (a-c):



a. Using a trim stick or similar tool, carefully separate the shifter bezel and boot assembly from the center console (Figure 4).



b. Insert a small screwdriver or similar tool down into the shift lever override access hole (at the right front corner of the shift lever assembly), and push and hold   the override release lever down (Figure 5).



c. Move the shift lever to the Figure 5 – Shift Lever Override NEUTRAL position.



  1. Raise and support the vehicle.



  1. Both front wheels; remove the five wheel mounting (lug) bolts then remove the tire and wheel assembly from the hub.



  1. Remove the fasteners (2) securing the front engine belly pan or front skid plate (1) to the underside of the vehicle, then remove the engine belly pan or skid plate (Figure 6).



  1. Latitude / Altitude / Limited / Overland: Remove the two outer rivets securing the wheelhouse splash shield to the front fascia on both sides of the vehicle (Figure 7).



  1. Upland / Trailhawk: Remove the single rivet securing the wheelhouse splash shield to the front fascia on both sides of the vehicle (Figure 8).



  1. If applicable, remove the fasteners securing the front fascia lower edge to the vehicle (Figure 9).



  1. Remove both front wheelhouse splash shields following steps (a-d):



a. Remove the screw securing the wheelhouse splash shield to the sill trim (Figure 10).



b. Remove the fasteners securing the wheelhouse splash shield to the vehicle (Figure 11).



NOTE: Fastener location and quantity will vary depending on vehicle trim level, (Figure 11) is only an example.



c. Release the outboard edge of the wheelhouse splash shield from the fender flange (Figure 11).

d. Remove the wheelhouse splash shield from the vehicle (Figure 11).



  1. Latitude / Altitude / Limited / Overland: From inside the wheel well, release the clips and remove the one-piece wheel flare molding from both sides of the vehicle (Figure 12).



  1. Upland / Trailhawk: Do NOT remove the two-piece front flare moldings (Figure 13).



  1. Remove the fastener on the inside of the wheel opening that attaches the side of the front fascia to the fender on both sides of the vehicle (Figure 14).



  1. Disconnect the front fascia electrical wire harness slide lock connector on the left side of the vehicle (Figure 15).



  1. Remove the push pin fasteners then remove the radiator closeout panel (Figure 16).



  1. If applicable based on trim level, remove the two screws securing the front fascia to the radiator core support (Figure 17).



  1. Carefully pull out on the upper and lower fascia sides to release the fascia retaining tabs at the fender and below the headlight. Repeat on the opposite side (Figure 18).



  1. Remove the fascia from the vehicle (Figure 18).



  1. If equipped, Disconnect the vehicle height sensor actuator rod (1) from the lower control arm (Figure 19).



  1. If equipped, Disconnect the wire harness connector (1) from the vehicle height sensor (Figure 20).



  1. If equipped, Remove the bolts (2) then remove the vertical bracket (1) from both sides of the vehicle(Figure 21).



  1. Where the stabilizer bar link attaches to the suspension strut, remove the nut while holding the stabilizer bar link stud stationary, then position the link aside (Figure 22).



  1. Remove and DISCARD the lower ball joint nut (Figure 23).



 NOTE: Discard the ball joint retaining nut. Use a NEW nut when installing the ball joint.



  1. Using ball joint press 4150A, separate the lower ball joint stud from the lower control arm (Figure 24).



NOTE: Make sure the ball joint boot does not get cut when separating the ball joint stud from the control arm.



  1. Remove and DISCARD the outer tie rod end nut (Figure 25).



 NOTE: Discard the tie rod retaining nut. Use a NEW nut when installing the tie rod.



  1. Using tie rod puller C-3894-A, separate the outer tie rod end from the steering knuckle (Figure 26).



  1. If applicable: Remove the nut securing the air intake resonator to the vehicle and position out of way (Figure 27).



  1. If equipped, remove the tow hook bolts (2) and remove the nut (5) then Remove the tow hook (1) (Figure 28).



  1. If equipped, remove the tow hook bracket bolts (3) and (4) then remove the tow hook bracket (6) (Figure 28).



  1. Remove the three bolts securing the lower load beam extensions to the radiator support (1). If the load beam extension is retained by clips, it is not necessary to remove the load beam extension from the vehicle (Figure 29).



  1. Remove the two bolts securing the lower load beam (2) to the cradle (3) (Figure 29).



  1. Remove the lower load beams (2) (Figure 29).



  1. Front Wheel Drive (FWD) vehicles, proceed to Page 23.

All Wheel Drive (AWD) / Four Wheel Drive (4WD) vehicles, remove the propeller shaft following steps (a-f):



a. Apply alignment index marks on the rear differential pinion flange and the rear propeller shaft flange for alignment during reassembly (Figure 30).



NOTE: Support the propeller shaft



b. Remove and DISCARD the six propeller shaft bolts at the rear pinion flange (Figure 30).



 CAUTION: Propeller shaft removal is a two-person operation. Never allow propeller shaft to hang from the center bearing, or while only connected to Power Transfer Unit (PTU) or rear driveline module flanges. A helper is required. If a propeller shaft section is hung unsupported, damage may occur to the joint, boot, and center bearing from over-angulation. This may result in driveline vibrations.



c. Remove the front center bearing bolts (Figure 31).

d. Remove the rear center bearing bolts (Figure 31).



e. Propeller shaft removal is a two-person operation. Remove the propeller shaft from the rear pinion flange then slide the propeller shaft off the Power Transfer Unit (PTU). Remove the propeller shaft from the vehicle. (Figure 32).



f. Replace the PTU output shaft snap ring with a NEW snap ring before the propeller shaft is reinstalled (Figure 33).



Exhaust System Crossunder Pipe:



  • Follow the appropriate crossunder pipe removal procedure for engine size: 0L (Page 23), 2.2L (Page 26), 2.4L (Page 30), or 3.2L (Page 33).



  • If any exhaust studs break during disassembly, remove the broken stud then use bolt part number 06512082AA to substitute for the broken stud and use the exhaust system nuts specified in the parts section of this recall campaign. Submit a consequential damage claim for stud replacement.



  1. 2.0L Engine: Remove the exhaust crossunder pipe following steps (a-h) (Figure 34).



  1. a. Remove and DISCARD the flange nuts (1) securing the crossunder pipe (2) to the catalyst (Figure 35).



2.0L Engine: Remove the exhaust crossunder pipe (Continued).



b. Loosen the exhaust clamp nut (1) securing the resonator (2) to the crossunder pipe (Figure 36).



c. Remove the bolts (1) securing the crossunder pipe rear isolators to the vehicle body (Figure 37).



d. Separate the crossunder pipe from thecatalyst and the resonator.



e. Support the exhaust system resonator (Figure 38).

f. Slide thecrossunder pipe rearward separating the pipe hanger from the front isolator (Figure 39).

g. Rotate and remove the crossunder pipe from the vehicle.

h. Remove and DISCARD the crossunder pipe tocatalyst flange gasket (1) (Figure 40).



  1. 2.2L Diesel Engine: Remove the exhaust crossunder pipe following steps (a-k) (Figure 41).



a. Disconnect the electrical connectors for the exhaust temperature sensor, Particulate (PM) sensor, and NOx sensor (Figure 42).

b. Release the wires from the retainers for the exhaust temperature sensor, Particulate (PM) sensor, and NOx sensor (Figure 43).



c. Remove the nuts (1), bolt (3) and the support bracket (2) (Figure 44).



d. Remove and DISCARD the flange nuts (1) securing the crossunder pipe to the Catalyst (Figure 45).



e. Remove the two bolts (1) securing the exhaust isolator to the front suspension crossmember (Figure 46).

f. Loosen the exhaust clamp nut (1) securing the resonator to the crossunder pipe (Figure 47).

g. Remove the bolts (1) securing the crossunder pipe rear isolator to the vehicle body (Figure 48).



h. Separate the crossunder pipe from the catalyst and the resonator.

i. Support the exhaust system resonator (Figure 49).

j. Rotate and remove the crossunder pipe from the vehicle.

k. Remove and DISCARD the crossunder pipe tocatalyst flange gasket (1) (Figure 50).



  1. 2.4L Engine: Remove the exhaust crossunder pipe following steps (a-h) (Figure 51).



a. Remove the and DISCARD flange nuts securing the crossunder pipe to the catalyst (Figure 52).

b. Remove the pipe support bolt (Figure 52).

c. Loosen the exhaust clamp nut securing the resonator to the crossunder pipe (Figure 53).

d. Remove the bolts securing the crossunder pipe rear isolator to the vehicle body (Figure 53).

e. Separate the crossunder pipe from thecatalyst and the resonator.

f. Support the exhaust system resonator (Figure 54).

g. Rotate and remove the crossunder pipe from the vehicle.

h. Remove and DISCARD the crossunder pipe to catalyst flange gasket (Figure 55).



  1. 3.2L Engine: Remove the exhaust crossunder pipe and Y-pipe following steps (a-m) (Figure 56).



a. Remove and DISCARD the rear crossunder pipe flange nuts securing the crossunder pipe to the Y-pipe (Figure 57).

b. Remove the crossunder pipe center support bolt (Figure 58).

c. Remove and DISCARD the front crossunder pipe flange nuts securing the cross under pipe to the catalyst (Figure 58).

d. Remove the crossunder pipe from the vehicle (Figure 56).

e. Remove and DISCARD the flange gasket between the crossunder pipe to front catalyst (Figure 59).

f. Remove and DISCARD the flange gasket between the crossunder pipe to Y-pipe (Figure 60).

g. Loosen the clamp nut securing the resonator pipe to the Y-pipe (Figure 61).

h. Support the exhaust system resonator.

i. Remove the exhaust Y-pipe isolator bolts (Figure 62).

j. Remove and DISCARD the Y-pipe flange nuts securing the Y-pipe to the rear catalyst (Figure 63).

k. Separate the Y-Pipe from the rear catalyst then position the Y-pipe to the left for removal clearance (Figure 64).

l. Separate the Y-pipe from the resonator pipe then remove the Y-pipe.

m. Remove and DISCARD the flange gasket between the Y-pipe to the rear catalyst (Figure 65).



All Vehicles:



NOTE: Before lowering the front suspension crossmember, the location of the crossmember must be marked on the body of the vehicle. Do this so the crossmember can be relocated, upon reinstallation, against the body of vehicle in the same location as before removal. If the front suspension crossmember is not reinstalled in exactly the same location as before removal, the preset front wheel alignment settings (caster and camber) may be lost.



  1. Mark the position of the crossmember with a grease pencil or equivalent (Figure 66).



  1. If Applicable: Remove the fasteners from the forward 1/3 of the plastic underbody shields to allow for shield flexibility and clearance while removing the front suspension crossmember. (Figure 67).



NOTE: This step does not apply to underbody metal skid plates that do not overlap the front suspension crossmember (Figure 68), Only the plastic shielding that overlaps the front suspension crossmember requires fastener removal (Figure 67).



  1. Support the engine/transmission assembly with a suitable stand (Figure 69).



  1. Remove the nut and bolt from the transmission pivot bracket end of the rear engine mount torque strut (Figure 70).



Suspension Crossmember and Steering Gear:



Follow the appropriate service procedure for Suspension Crossmember and Steering Gear Removal:



  • All Wheel Drive (AWD) / Four Wheel Drive (4WD) Page 40.



  • Front Wheel Drive (FWD) Page 45.



Suspension Crossmember and Steering Gear Removal for AWD / 4WD configuration ONLY.



  1. AWD/4WD only: Place the steering gear tie rod ends loosely into the steering knuckle for support. Do NOT secure the tie rod ends, this is only for steering gear support during removal of front suspension crossmember (Figure 71).



  1. AWD/4WD only: Remove the nuts securing the steering gear to the suspension crossmember (Figure 72).



NOTE: Place a wrench on the steering gear bolts to prevent rotation while removing the nuts.



  1. Remove the four lower rear bolts securing the suspension crossmember to the underbody NOT the front side upper bolts (Figure 73).



CAUTION: Leave the front side upper bolts securing the suspension crossmember to the frame rails securely in place until the crossmember is supported in the next step.



  1. AWD/4WD only: support the suspension crossmember with a transmission jack, or equivalent (Figure 74).



  1. Remove the two upper front tower bolts securing the suspension crossmember to the frame rails (Figure 75).



 NOTE: The next step may be easier with the assistance of another technician.



  1. AWD/4WD only: Lower the suspension crossmember down away from the vehicle while separating the ball joints from the lower control arms and the steering gear bolts from the suspension crossmember. Guide the front suspension stabilizer bar past the PTU output shaft.



  1. Keep the steering gear supported on the top of PTU assembly also tie rod ends loosely placed in steering knuckle for additional support (Figure 76).



  1. Release the shift cable retainer from the steering gear heat shield bracket (Figure 77).



  1. AWD/4WD only: Disconnect the two vehicle wire harness electrical connectors from the steering gear (Figure 78).



  1. AWD/4WD only: Release the vehicle wire harness retainer from the steering gear housing (Figure 79).



  1. AWD/4WD only: Using an adjustable length belt strap attached between the vehicle structure and engine, rotate the bottom of the engine and transmission assembly forward tilting the PTU down to create enough space for removal of the steering gear from the vehicle (Figure 80).



NOTE: Rotating of the engine may also be accomplished with the assistance of another technician if an adjustable belt strap is not available.



  1. AWD/4WD only: Remove the tie rod ends from the steering knuckles then tilt and remove the steering gear from the vehicle (Figure 81).



Suspension Crossmember and Steering Gear Removal for FWD configuration ONLY.



  1. FWD only: Remove the four lower rear bolts securing the suspension crossmember to the underbody NOT the front side upper bolts (Figure 82).



CAUTION: Leave the front side upper bolts securing the suspension crossmember to the frame rails securely in place until the crossmember is supported in the next step.



  1. FWD only: support the suspension crossmember with a transmission jack, or equivalent (Figure 83).



  1. FWD only: Remove the two upper front tower bolts securing the suspension crossmember to the frame rails (Figure 84).



  1. FWD only: Lower the suspension crossmember only slightly just enough to gain access to the shift cable retainer and steering gear electrical connectors.



  1. FWD only: Release the shift cable retainer from the steering gear heat shield bracket (Figure 85).



  1. FWD only: Disconnect the two vehicle wire harness electrical connectors from the steering gear (Figure 86).



  1. FWD only: Release the vehicle wire harness retainer from the steering gear housing (Figure 87).





NOTE: The next step may be easier with the assistance of another technician.



  1. FWD only: Lower the suspension crossmember and steering gear down away from the vehicle while separating the ball joints from the lower control arms.



  1. FWD only: Remove the nuts securing the steering gear to the suspension crossmember.



  1. FWD only: Separate the steering gear from the suspension crossmember.



All Vehicles:



  1. Unbox the new steering gear and remove all shipping plugs and material.



  1. Transfer the heat shield, bracket, and fasteners from the old steering gear to the new steering gear. Tighten the fasteners to 8 N·m (71 in. lbs.) (Figures 88).



  1. Transfer the dash seal and fastener from the old steering gear to the new steering gear. Tighten the fastener to 2.5 N·m (22 in. lbs.) (Figure 89).



B. Steering Gear Installation:



Follow the appropriate service procedure for Suspension Crossmember and Steering Gear Installation:



  • Front Wheel Drive (FWD) Page 49.



  • All Wheel Drive (AWD) / Four Wheel Drive (4WD) Page 51.



Suspension Crossmember and Steering Gear installation for FWD configuration ONLY.



  1. FWD only: Position the steering gear to the suspension crossmember.



  1. FWD only: Install the NEW bolts and NEW nuts securing the steering gear to the suspension crossmember. Tighten the nuts to 97 N·m (72 ft. lbs.).



NOTE: The next step may be easier with the assistance of another technician.



  1. FWD only: Support the crossmember with steering gear using a transmission jack, or equivalent (Figure 83). Raise the suspension crossmember to the vehicle while aligning the ball joints to the lower control arms and the steering gear input shaft with the dash panel opening.



  1. FWD only: Attach the wire harness retainer to the steering gear (Figure 87).



  1. FWD only: Connect the two vehicle wire harness electrical connectors to the steering gear (Figure 86).



Suspension Crossmember and Steering Gear installation for FWD configuration ONLY. (Continued)



  1. FWD only: Attach the shift cable retainer to the steering gear heat shield bracket (Figure 85).



  1. FWD only: Install the two upper front tower bolts (1) securing the suspension crossmember to the frame rails but do not tighten the bolts at this time (Figure 90).



  1. FWD only: Lower the transmission jack, or equivalent supporting the suspension crossmember (Figure 83).



  1. FWD only: Install the four lower rear inner (3) and outer (2) bolts securing the suspension crossmember to the underbody but do not tighten the bolts at this time (Figure 90).



  1. FWD only: Check the position of the suspension crossmember to the alignment marks made previously on the vehicle body



  1. FWD only: Tighten the suspension crossmember bolts (Figure 90) to:
    • (1) Front Tower Bolts 175 N·m (129 ft. lbs.).
    • (2) Rear Outer Bolts 96 N·m + 110° (71 ft. lbs. + 110°).
    • (3) Rear Inner Bolts 55 N·m + 130° (41 ft. lbs. + 110°).



Suspension Crossmember and Steering Gear Installation for AWD / 4WD configuration ONLY.



  1. AWD/4WD only: Insert the NEW long bolts into the steering gear. Positon the steering gear to the vehicle on the top of PTU assembly and place the tie rod ends into the steering knuckles for additional support of the steering gear (Figure 81).



  1. AWD/4WD only: If a belt strap was used to rotate the bottom of the engine and transmission assembly forward, the belt strap may be removed (Figure 80).



  1. AWD/4WD only: Attach the vehicle wire harness retainer to the steering gear housing (Figure 79).



  1. AWD/4WD only: Connect the two vehicle wire harness electrical connectors to the steering gear (Figure 78).



  1. AWD/4WD only: Attach the shift cable retainer to the steering gear heat shield bracket (Figure 77).



  1. AWD/4WD only: Support the crossmember using a transmission jack, or equivalent (Figure 74). Raise the suspension crossmember to the vehicle while guiding the front suspension stabilizer bar past the PTU output shaft while aligning the ball joints to the lower control arms, aligning the steering gear mounting bolts to the crossmember, and align the crossmember with the alignment marks made previously on the vehicle body (Figure 66).



Suspension Crossmember and Steering Gear Installation for AWD / 4WD configuration ONLY.



  1. AWD/4WD only: Install the two upper front tower bolts (1) securing the suspension crossmember to the frame rails but do not tighten the bolts at this time (Figure 91).



  1. AWD/4WD only: Lower the transmission jack, or equivalent supporting the suspension crossmember (Figure 74).



  1. AWD/4WD only: Install the four lower rear inner (3) and outer (2) bolts securing the suspension crossmember to the underbody but do not tighten the bolts at this time (Figure 91).



  1. AWD/4WD only: Check the position of the suspension crossmember to the alignment marks made previously on the  vehicle body (Figure 66).



  1. AWD/4WD only: Tighten the suspension crossmember bolts (Figure 91) to:
    • (1) Front Tower Bolts 175 N·m (129 ft. lbs.).
    • (2) Rear Outer Bolts 96 N·m + 110° (71 ft. lbs. + 110°).
    • (3) Rear Inner Bolts 55 N·m + 130° (41 ft. lbs. + 110°).



  1. AWD/4WD only: Install the NEW nuts securing the steering gear to the suspension crossmember. Tighten the nuts to 97 N·m (72 ft. lbs.) (Figure 72).



All Vehicles:



  1. Install the rear engine mount torque strut to transmission pivot bracket bolt and nut. Tighten to 115 N·m (85 ft. lbs.) (Figure 70).



  1. Remove the engine/transmission assembly support stand (Figure 69).



  1. If Applicable: Install the fasteners previously removed from the forward 1/3 of the plastic underbody shields (Figure 67).



Exhaust System Crossunder Pipe:



  • Follow the appropriate crossunder pipe installation procedure for engine size: 0L (Page 57), 2.2L (Page 56), 2.4L (Page 55), or 3.2L (Page 54).



  • If any exhaust studs broke during disassembly, remove the broken stud then use bolt part number 06512082AA to substitute for the broken stud and use the exhaust system nuts specified in the parts section of this recall campaign. Submit a consequential damage claim for stud replacement.



  1. 2L Engine: Install the exhaust crossunder pipe and Y-pipe following steps (a-l).



a. Install a NEW flange gasket between the Y-pipe and rear catalyst (Figure 65).

b. Position the Y-pipe to the vehicle and attach the Y-pipe to the resonator pipe and the catalyst.

c. Install the NEW nuts securing the Y-pipe flange to the rear catalyst. Tighten the nuts to 32 N·m (24 ft. lbs.) (Figure 63).

d. Install the exhaust Y-pipe isolator bolts. Tighten the bolts to 20 N·m (15 ft. lbs.) (Figure 62).

e. Tighten the clamp nut to 16 N·m (12 ft. lbs) securing the resonator pipe to the Y-pipe (Figure 61).

f. Remove the support from the exhaust system resonator.

g. Install a NEW flange gasket between the crossunder pipe and Y-pipe (Figure 60).

h. Install a NEW flange gasket (1) between the crossunder pipe and catalyst (Figure 59).

i. Install the crossunder pipe to the vehicle (Figure 56).

j. Install the NEW nuts securing the cross under pipe flange to the catalyst. Tighten the nuts to 32 N·m (24 ft. lbs.) (Figure 58).

k. Install the crossunder pipe center support bolt. Tighten the bolt to 20 N·m (15 ft. lbs.) (Figure 58).

l. Install the NEW nuts securing the cross under pipe flange to the Y-pipe. Tighten the nuts to 32 N·m (24 ft. lbs.) (Figure 57).



  1. 4L Engine: Install the exhaust crossunder pipe following steps (a-h) (Figure 51).



a. Install a NEW flange gasket to the catalyst flange (Figure 55).

b. Install the crossunder pipe to the vehicle.

c. Install the crossunder pipe to the catalyst and the resonator.

d. Install the bolts securing the crossunder pipe rear isolator to the vehicle body. Tighten the bolts to 20 N·m (15 ft. lbs.) (Figure 53).

e. Install the NEW nuts securing the crossunder pipe flange to the catalyst. Tighten the nuts to 32 N·m (24 ft. lbs.) (Figure 52).

f. Install the pipe support bracket bolt. Tighten the bolt to 20 N·m (15 ft. lbs) (Figure 52).

g. Tighten the exhaust clamp nut securing the resonator to the crossunder pipe to 16 N·m (12 ft. lbs) (Figure 53).

h. Remove the support from under the exhaust system resonator (Figure 54).



  1. 2L Diesel Engine: Install the exhaust crossunder pipe following steps (a-k) (Figure 41).



a. Install a NEW flange gasket (1) to the catalyst (Figure 50).

b. Install the crossunder pipe to the vehicle.

c. Install the crossunder pipe to the catalyst and the resonator.

d. Install the bolts (1) securing the crossunder pipe rear isolator to the vehicle body. Tighten the bolts to 26 N·m (19 ft. lbs.) (Figure 48).

e. Tighten the exhaust clamp nut (1) to 55 N·m (41 ft. lbs) securing the resonator to the crossunder pipe (Figure 47).

f. Install the two bolts (1) securing the exhaust isolator to the front suspension crossmember. Tighten the bolts to 18 N·m (13 ft. lbs.) (Figure 46).

g. Install the NEW nuts (1) securing the crossunder pipe to the Catalyst. Tighten the nuts to 26 N·m (19 ft. lbs.) (Figure 45).

h. Install the support bracket (2), nuts (1), and bolt (3). Tighten the nuts to 22 N·m (16 ft. lbs.) and tighten the bolt to 25 N·m (18 ft. lbs.) (Figure 44).

i. Install the wires to the retainers for the exhaust temperature sensor, Particulate (PM) sensor, and NOx sensor (Figure 43).

j. Connect the electrical connectors for the exhaust temperature sensor, Particulate (PM) sensor, and NOx sensor (Figure 42).

k. Remove the support from the exhaust system resonator (Figure 49).



  1. 0L Engine: Install the exhaust crossunder pipe following steps (a-g). (Figure 34).



a. Install a NEW flange gasket (1) to the catalyst flange (Figure 40).

b. Install the crossunder pipe to the vehicle while sliding the crossunder pipe hanger into the front isolator (Figure 39).

c. Install the crossunder pipe to the catalyst and the resonator.

d. Install the bolts (1) securing the crossunder pipe rear isolator to the vehicle body. Tighten the bolts to 20 N·m (15 ft. lbs.) (Figure 37).

e. Tighten the exhaust clamp nut (1) to 16 N·m (12 ft. lbs) securing the resonator (2) to the crossunder pipe (Figure 36).

f. Install the NEW nuts (1) securing the crossunder pipe flange to the catalyst. Tighten the nuts to 32 N·m (24 ft. lbs.) (Figure 35).

g. Remove the support from the exhaust system resonator (Figure 38).



  1. Front Wheel Drive (FWD) vehicles, proceed to Page 60.

 All Wheel Drive (AWD) / Four Wheel Drive (4WD) vehicles, install the propeller shaft following steps (a-h):



CAUTION: Propeller shaft installation is a two-person operation. Never allow propeller shaft to hang from the center bearing, or while only connected to power transfer unit (PTU) or rear driveline module flanges. A helper is required. If a propeller shaft section is hung unsupported, damage may occur to the joint, boot, and center bearing from overangulation. This may result in driveline vibrations.



a. Replace the Power Transfer Unit (PTU) output shaft snap ring with a NEW snap ring before the propeller shaft is reinstalled (Figure 33).

b. Lightly apply grease to the PTO splines prior to installation.

c. With the aid of a helper, install the propeller shaft into the PTU by wiggling the plug-on joint back and forth while pushing forward until splines engage and propeller shaft is fully seated (Figure 32).



NOTE: If the snap ring is fully engaged, the propeller shaft will not be removable from the PTU by hand.



d. Perform the push/pull test to verify joint is fully seated over snap ring.

e. Position the rear center bearing in place, install the rear center bearing bolts and tighten the bolts to 23 N·m (17 ft. lbs.) (Figure 31).

f. Position the front center bearing in place, install the front center bearing bolts and tighten the bolts to 23 N·m (17 ft. lbs.) (Figure 31).

g. Align the index marks on the rear propeller shaft flange and the rear pinion flange (Figure 30).



Propeller shaft installation AWD / 4WD configuration ONLY. (Continued)



NOTE: The six bolts that are used to secure the propeller shaft to the Rear Drive Unit (RDU) input flange MUST be replaced. Do not reuse the bolts/washers.



NOTE: Use of Anti-seized compound is prohibited.



NOTE: Make sure the double washer is flat/flush to the joint housing prior to tightening the bolt to avoid damage to the washer, if damaged replace bolt washer assembly.



NOTE: No torque verification is allowed after 10 minutes of the bolts being tightened to specifications. ANY MANIPULATION of the bolts after 10 minutes of being tightened will require the bolt(s) to be replaced.



h. Install NEW propeller shaft bolts and tighten the bolts to 21 N·m (15 ft. lbs.) (Figure 30).



All Vehicles:



  1. Install the lower load beams (2) (Figure 29).



  1. Install the two bolts securing the lower load beam (2) to the cradle (3). Tighten the bolts to 89 N·m (65 ft. lbs.) (Figure 29).



  1. Install the lower load beam extensions and bolts securing the load beam extensions to the radiator support (1). Tighten the bolts to 45 N·m (33 ft. lbs.) (Figure 29).



  1. If equipped, install the tow hook bracket (6) and the tow hook bracket bolts (3) and (4). Tighten the tow hook bracket to rail bolts (3) to 26 N·m (19 ft. lbs.). Tighten the tow hook bracket to load beam bolt (4) to 45 N·m (33 ft. lbs.) (Figure 27).



  1. If equipped, install the tow hook (1), tow hook bolts (2) and nut (5). Tighten the bolts (2) to 47 N·m (35 ft. lbs.) and nut (5) to 25 N·m (18 ft. lbs.) (Figure 27).



  1. If applicable: Install the nut securing the air intake resonator to the vehicle (Figure 27).



NOTE: Use a NEW nut when installing the outer tie rod.



  1. Install the outer tie rod end stud into the hole in the knuckle arm. Install a NEW nut on the outer tie rod end stud. While holding the tie rod end stud with a wrench, tighten to the nut to 40 N·m + 165° (30 ft. lbs. + 165°) (Figure 25).



NOTE: Use a NEW nut when installing the lower ball joint.



  1. Install a NEW nut on the lower ball joint. Tighten the nut to 30 N·m + 95° (22 ft. lbs. + 95°) (Figure 23).



  1. Position the stabilizer bar link to the strut. Install the nut securing the stabilizer bar link to strut. Tighten the nut to 60 N·m (44 ft. lbs.) (Figure 22).



  1. If equipped, Install the vertical bracket (1) and the bolts (2) on both sides of the vehicle. Tighten the bolts to 27 N·m (20 ft. lbs.) (Figure 21).



  1. If equipped, Connect the wire harness connector (1) to the vehicle height sensor (Figure 20).



  1. If equipped, Connect the vehicle height sensor actuator rod (1) to the lower control arm (Figure 19).



  1. Position the fascia to the vehicle (Figure 18).



  1. Seat the fascia onto the clips under the headlights fully (Figure 18).



  1. Seat the sides of the fascia onto the fender clips fully (Figure 18).



  1. If applicable based on trim level, install the two screws securing the front fascia to the radiator core support (Figure 17).



  1. Install the radiator closeout panel to the vehicle then install the push pin fasteners (Figure 16).



  1. Connect the front fascia electrical wire harness slide lock connector on the left side of the vehicle (Figure 15).



  1. Install the fastener on the inside of the wheel opening that attaches the side of the front fascia to the fender on both sides of the vehicle (Figure 14).



  1. Latitude / Altitude / Limited / Overland: Install the one-piece wheel flare molding engage the clips on both sides of the vehicle (Figure 12).



  1. Install both front wheelhouse splash shields to the vehicle following steps (a-c).



a. Engage the outboard edge of the wheelhouse splash shield to the fender flange (Figure 11).

b. Install the fasteners securing the wheelhouse splash shield to the vehicle (Figure 11).

c. Install the screw securing the wheelhouse splash shield to the sill trim (Figure 10).



  1. If applicable, install the fasteners securing the front fascia lower edge to the vehicle (Figure 9).



  1. Upland / Trailhawk: Install the single rivet securing the wheelhouse splash shield to the front fascia on both sides of the vehicle (Figure 8).



  1. Latitude / Altitude / Limited / Overland: Install the two outer rivets securing the wheelhouse splash shield to the front fascia on both sides of the vehicle (Figure 7).



  1. Install the engine belly pan or skid plate (1) to the vehicle then install the fasteners (2) (Figure 6).



  1. Install Both front wheels to the hub then install the five wheel mounting (lug) bolts. Tighten the wheel mounting (lug) bolts to 135 N·m (100 ft. lbs.).



  1. Lower the vehicle.



  1. Front Wheel Drive (FWD) vehicles, proceed to Step 56.

All Wheel Drive (AWD) / Four Wheel Drive (4WD) vehicles, place the transmission in PARK following steps (a-b).



a. Install the shifter bezel and boot assembly to the center console (Figure 4).

b. Place the shift lever in the park position.



  1. Install the intermediate shaft to the steering gear pinion shaft then install a NEW intermediate shaft pinch bolt. Tighten the bolt to 25 N·m (18 ft. lbs.) (Figure 3).



  1. Remove the steering wheel holder (Figure 1).



  1. Connect the ground cable eyelet to the IBS terminal then install the M8 hex nut. Tighten the nut to 11 N·m (8 ft. lbs.) (Figure 2).



  1. Connect the Intelligent Battery Sensor (IBS) wire harness connector (Figure 2).



  1. Proceed to Section C. Programming and Alignment.



C. Programming and Alignment



NOTE: The wiTECH scan tool must be used to perform this recall.  If the reprogramming flash for the EPS is aborted or interrupted, repeat the procedure.



CAUTION: the EPS software must be at the latest software calibration level after completing this recall.



  1. Open the hood and install a battery charger. Verify that the charging rate provides 13.0 to 13.5 volts. Do not allow the charger to time out during the flash process.  Set the battery charger timer (if so equipped) to continuous charge.



NOTE:  Use an accurate stand-alone voltmeter.  The battery charger volt meter may not be sufficiently accurate.  Voltages outside of the specified range will cause an unsuccessful flash.  If voltage reading is too high, apply an electrical load by activating the park or headlamps and/or HVAC blower motor to lower the voltage.



  1. Connect the wiTECH micro pod II to the vehicle data link connector.



  1. Place the ignition in the “RUN” position.



  1. Open the wiTECH 2.0 website.



  1. Enter your “User id” and “Password” and your “Dealer Code”, then select “Sign In” at the bottom of the screen.  Click “Accept”.



  1. From the “Vehicle Selection” screen, select the vehicle to be updated.



  1. From the “Action Items” screen, select the “Topology” tab.



  1. From the “Topology” tab, select the “EPS” module icon.



  1. From the “Flash” tab, compare the “Current Electronic Control Unit (ECU) Part Number” with the “New ECU Part Number” listed.
    • If the “Current ECU part Number” is the same as the “New Part Number”, proceed to Step 15.
    • If the “Current ECU part Number” is NOT the same as the “New Part Number”, continue with Step 10.



  1. From the EPS tab, select the EPS flash part number. Read the flash special instructions page.  Select “OK” to continue.



  1. From the flash ECU agreement page, agree to terms by checking the box.



  1. Select “Flash ECU” and then follow the wiTECH screen instructions to complete the flash.



  1. Confirm the software is at the latest available calibration level.



  1. Click “View DTCs”, select “Clear All DTCs”, click “Continue” and then click “Close”.



  1. Select vehicle view screen.



  1. Select guided diagnostic under activities tab.



  1. Select “Proxi Configuration Alignment” follow screen prompts.



  1. Click “View DTCs”, select “Clear All DTCs”, click “Continue” and then click “Close”.



  1. Select the “ Functions” tab.



  1. Select “EPS Learn” follow screen prompts.



  1. Click “View DTCs”, select “Clear All DTCs”, click “Continue” and then click “Close”.



  1. Perform eps verification test: Start the engine then turn the steering wheel from stop to stop then back to center.



  1. Place the ignition in the “OFF” position and then remove the wiTECH micro pod II device from the vehicle.



  1. Remove the battery charger from the vehicle.



  1. Perform a wheel alignment to proper specifications.



  1. Return the vehicle to inventory or the customer.



Completion Reporting and Reimbursement

Claims for vehicles that have been serviced must be submitted on the DealerCONNECT Claim Entry Screen located on the Service tab.   Claims paid will be used by FCA to record recall service completions and provide dealer payments.

Use the following labor operation numbers and time allowances:

Labor Operation
Number
Time
Allowance
Replace Steering Gear: 2.0L, 2.2L, 2.4L 19-V9-91-81 4.3 hours
Replace Steering Gear: 3.2L 19-V9-91-82 4.6 hours
Related Operations
Tow Hook Equipped 19-V9-91-60 0.4 hours
4X4 / AWD Equipped 19-V9-91-61 0.4 hours
Vehicle Height Sensor Equipped 19-V9-91-62 0.2 hours
Floor Plan Reimbursement 95-95-95-97 Calculate See Below



Floor Plan Reimbursement represents the vehicle’s average daily allowance (see table below) multiplied by the number of days the vehicle was in dealer inventory and not available for sale.  This reimbursement is limited to the number of days from the date of the stop sale to the date that the remedy was made available.  Note:  If the vehicle was received by your dealership (KZX date) AFTER the stop sale date, you will use the KZX date instead of the stop sale date.  For this Recall, the stop sale was initiated on 09/05/2019 and the remedy was made available on 10/24/2019, therefore, the number of days cannot exceed 49 days.

Vehicle Average Daily Allowance
2019 and 2020 (KL) Jeep Cherokee



Add the cost of the recall parts package plus applicable dealer allowance to your claim.



NOTE:  See the Warranty Administration Manual, Recall Claim Processing Section, for complete recall claim processing instructions.



NOTE: No additional parts are anticipated for this campaign. If any exhaust studs broke during disassembly, use bolt part number 06512082AA to substitute for the broken stud and use the exhaust system nuts specified in the parts section of this recall campaign. Submit a consequential damage claim for stud replacement, the dealer must first check if a related LOP has been created for repairs prior to performing the repair. If no related LOP is found, the LOP review process must be followed to request a related Recall LOP be added as follows:



Submit a LOP Related Inquiry (located in DealerCONNECT > Service > Claim Administration) for evaluation and update.

  • IF the request is approved – the related Recall LOP will be added to the Labor Operations and you are to proceed with normal Recall claim entry process.
  • IF the request is not approved – submit the repair under Warranty (W) if the repair has been pre-authorized by your Area Manager or Business Center representative.



Dealer Notification

To view this notification on DealerCONNECT, select “Global Recall System” on the Service tab, then click on the description of this notification.



Owner Notification and Service Scheduling

All involved vehicle owners known to FCA are being notified of the service requirement by first class mail.  They are requested to schedule appointments for this service with their dealers.  A generic copy of the owner letter is attached.



Vehicle Lists, Global Recall System, VIP and Dealer Follow Up

All involved vehicles have been entered into the DealerCONNECT Global Recall System (GRS) and Vehicle Information Plus (VIP) for dealer inquiry as needed.

GRS provides involved dealers with an updated VIN list of their incomplete vehicles.  The owner’s name, address and phone number are listed if known.  Completed vehicles are removed from GRS within several days of repair claim submission.

To use this system, click on the “Service” tab and then click on “Global Recall System.”  Your dealer’s VIN list for each recall displayed can be sorted by: those vehicles that were unsold at recall launch, those with a phone number, city, zip code, or VIN sequence.

Dealers must perform this repair on all unsold vehicles before retail delivery. Dealers should also use the VIN list to follow up with all owners to schedule appointments for this repair.

Recall VIN lists may contain confidential, restricted owner name and address information that was obtained from the Department of Motor Vehicles of various states.  Use of this information is permitted for this recall only and is strictly prohibited from all other use.



Additional Information

If you have any questions or need assistance in completing this action, please contact your Service and Parts District Manager.

Customer Services / Field Operations

FCA US LLC


This notice applies to your vehicle,

 [Model Year and Model]  VIN XXXXXXXXXXXXXXXXX V99/NHTSA 19V-637



LOGO

VEHICLE PICTURE

YOUR SCHEDULING OPTIONS



  1. RECOMMENDED OPTION Call your authorized Chrysler / Dodge / Jeep® / RAM Dealership



  1. Call the FCA Recall Assistance Center at 1-800-853-1403. An agent can confirm part availability and help schedule an appointment



  1. Visit recalls.mopar.com, scan the QR code below, or download the Mopar Owner’s Companion App.



QR Code



Get access to recall notifications, locate your nearest dealer, and more through this website or Mopar Owner’s Companion App. You will be asked to provide your Vehicle Identification Number (VIN) to protect and verify your identity. The last eight characters of your VIN are provided above.



DEALERSHIP INSTRUCTIONS

Please reference Safety Recall V99.


IMPORTANT SAFETY RECALL

Steering Gear



Dear [Name],

This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.



FCA US has decided that a defect, which relates to motor vehicle safety, exists in certain [2019 and 2020 Model Year (KL) Jeep® Cherokee] vehicles.

It is extremely important to take steps now to repair your vehicle to ensure the safety of you and your passengers.



WHY DOES MY VEHICLE NEED REPAIRS?

The steering gear on your vehicle [1] may have been built with a servo pinion hardness below specification. This could potentially result in a fracture and allow a metal shard to become lodged within the teeth of the steering rack. If this occurs, it can result in a loss of steering control which can cause a vehicle crash without prior warning.



HOW DO I RESOLVE THIS IMPORTANT SAFETY ISSUE?

FCA US will repair your vehicle [2] free of charge (parts and labor).  To do this, your dealer will replace the steering gear. The estimated repair time is six hours. In addition, your dealer will require your vehicle for proper check-in, preparation, and check-out during your visit, which may require more time. Your time is important to us, so we recommend that you schedule a service appointment to minimize your inconvenience. Please bring this letter with you to your dealership.



TO SCHEDULE YOUR FREE REPAIR,
CALL YOUR CHRYSLER, DODGE, JEEP OR RAM DEALER TODAY



WHAT IF I ALREADY PAID TO HAVE THIS REPAIR COMPLETED?

If you have already experienced this specific condition and have paid to have it repaired, you may visit www.fcarecallreimbursement.com to submit your reimbursement request online. [3] Once we receive and verify the required documents, reimbursement will be sent to you within 60 days.  If you have had previous repairs performed and/or already received reimbursement, you may still need to have the recall repair performed.



We apologize for any inconvenience, but are sincerely concerned about your safety.  Thank you for your attention to this important matter.

Customer Assistance/Field Operations

FCA US LLC


Mr. Mrs. Customer
1234 Main Street
Hometown, MI 48371

[1] If you no longer own this vehicle, please help us update our records. Call the FCA Recall Assistance Center at 1-800-853-1403 to update your information.

[2] If your dealer fails or is unable to remedy this defect without charge and within a reasonable time, you may submit a written complaint to the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave., S.E., Washington, DC  20590, or you can call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-4249153), or go to safercar.gov.

[2] You can also mail in your original receipts and proof of payment to the following address for reimbursement consideration: FCA Customer Assistance, P.O. Box 21-8004, Auburn Hills, MI 48321-8007, Attention: Recall Reimbursement.



Note to lessors receiving this recall notice: Federal regulation requires that you forward this recall notice to the lessee within 10 days.




09/05/2019

New Safety Recall Advanced Communication – V99



FCA US LLC (FCA US) has announced a safety recall on certain 2019 and 2020 Model Year (KL) Jeep® Cherokee vehicles.

VINs identified as being involved in this campaign are currently live and searchable. Stop sale is in effect for the above-identified vehicles.

 Vehicles impacted by a stop sale are eligible for reimbursement allowance through the Recall Floorplan Reimbursement Policy (RFPRP), which can be requested upon recall claim submission.

IMPORTANT:  Some of the involved vehicles may be in dealer new vehicle inventory.  Federal law requires you to complete this recall service on these vehicles before retail delivery.  Violation of this requirement by a dealer could result in a civil penalty of up to $21,000 per vehicle.  Involved vehicles can be determined by using the VIP inquiry process.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with a steering gear servo pinion hardness below specification, which could potentially result in a fracture allowing a metal shard to become lodged within the teeth of the steering rack. If this occurs, it can result in a loss of steering control which can cause a vehicle crash without prior warning.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to replace the steering gear. The remedy for this condition is not currently available.  Dealers will be notified of the launch of this safety recall by way of established communication methods.  This recall is estimated to launch in 3rd Quarter of 2019.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.





Customer Services Field Operations

FCA US LLC




08/30/2019

New Safety Recall Advanced Communication – V99



FCA US LLC (FCA US) has announced a safety recall on certain 2019 and 2020 Model Year (KL) Jeep® Cherokee vehicles.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with a steering gear servo pinion hardness below specification, which could potentially result in a fracture allowing a metal shard to become lodged within the teeth of the steering rack. If this occurs, it can result in a loss of steering control which can cause a vehicle crash without prior warning.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to replace the steering gear. The remedy for this condition is not currently available.  Dealers will be notified of the launch of this safety recall by way of established communication methods.  This recall is estimated to launch in 3rd Quarter of 2019.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.



Customer Services Field Operations

FCA US LLC




2 Affected Products

Vehicle

MAKE MODEL YEAR
JEEP CHEROKEE 2019-2020




11 Associated Documents

Remedy Instructions and TSB

RCRIT-19V637-6423.pdf 4476.826KB

RCRIT-19V637-6423




ISSUED Renotification Notice

RCRN-19V637-9270.pdf 140.506KB

RCRN-19V637-9270




Remedy Instructions and TSB

RCRIT-19V637-5539.pdf 4476.898KB

RCRIT-19V637-5539




Recall Quarterly Report #2, 2020-1

RCLQRT-19V637-6774.PDF 211.237KB

RCLQRT-19V637-6774




Recall Quarterly Report #1, 2019-4

RCLQRT-19V637-3815.PDF 211.137KB

RCLQRT-19V637-3815




Owner Notification Letter(Part 577)

RCONL-19V637-5999.pdf 516.634KB

RCONL-19V637-5999




Manufacturer Notices(to Dealers,etc) – 08/30/2019 New Safety Recall Advanced Communication – V99

RCMN-19V637-6952.pdf 97.572KB

RCMN-19V637-6952




Manufacturer Notices(to Dealers,etc) – 09/05/2019 New Safety Recall Advanced Communication – V99

RCMN-19V637-4620.pdf 100.467KB

RCMN-19V637-4620




Recall Acknowledgement

RCAK-19V637-5352.pdf 244.099KB

RCAK-19V637-5352




Defect Notice 573 Report

RCLRPT-19V637-7554.PDF 213.971KB

RCLRPT-19V637-7554




Recall Quarterly Report #3, 2020-2

RCLQRT-19V637-5247.PDF 211.322KB

RCLQRT-19V637-5247




Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=19V637&docType=RCL






Bestseller No. 1
Rough Country HD Steering Kit w/Stabilizer for Jeep (TJ,XJ,ZJ,MJ) - 10613
  • Heavy Duty Replacement Tie-Rod / Tie Rod Ends / Drag Link | N3 Single Steering Damper.
  • Rotational Non-Articulating Joints | Prevents Bump Steer / Tighter Steering | Dependable Against Off-Road Obstacles.
  • Higher Clearance | Massive / Durable 1.5 inch DOM Tubing.
  • Engineered with Wrench Flats | Eases of Installation / Adjustability | Supported by RC.
  • Backed by Rough Country's Limited Lifetime Replacement Warranty.
Bestseller No. 2
Jeep Steering Auto Wheel Cover With Fancy Jeep Keychain
  • This Listing is for a 1pc Steering Wheel Cover
  • Made of Quality Synthetic Leather
  • Protects your Vehicle from wear and tear
  • Fits MOST Steering Wheel Covers: 14.5" - 15.5" Inches
  • Easy to install and protects against wear and tear
Bestseller No. 3
Rough Country N3 Dual Steering Stabilizer for 07-18 Jeep Wrangler JK - 8734930
  • Give your Wrangler JK the Perfect Blend of Performance and Stability from Rough Country.
  • Improves Control and Handling.
  • Reduces "bump steer" and Vibration | Added Life to Tires, Ball Joints, and other Steering Components.
  • Easy Bolt-On Installation, Supported by RC.
  • Backed by Rough Country's Limited Lifetime Replacement Warranty.
Bestseller No. 4
JEEP JK 1 TON 7075 ALUMINIUM STEERING (NO DRILLING REQUIRED)
  • JEEP JK 1 TON 7075 ALUMINIUM STEERING (NO DRILLING REQUIRED)
  • JK Steering Upgrade
  • Aluminum Steering
SaleBestseller No. 5
Plasticolor 006695R01 Jeep Deluxe High Contrast Stitching Premium Steering Wheel Cover for Cars, Trucks & SUV
  • ?? HIGH CONTRAST STITCHING ? Let your New Jeep Logo Steering Wheel Cover Pop with Plasticolors incredible High Contrast Stitching. This bold, fashionable new look really stands out compared to other standard covers.
  • ?? OFFICIALLY LICENSED - Our Jeep logo wheel cover is officially licensed by Jeep.
  • ?? THE IDEAL FIT - Our Deluxe Jeep logo wheel cover is perfect for any standard size steering wheel that measures from 14.5?-15.5?. Slip-on design makes for easy installation.
  • ?? QUALITY - Embossed for durability and style, steering wheel cover boasts a comfortable leather-like feel.
  • International products have separate terms, are sold from abroad and may differ from local products, including fit, age ratings, and language of product, labeling or instructions.
Bestseller No. 6
Car Truck SUV Black Grip Steering Wheel Cover - Speed for Jeep
  • Specially formulated to eliminate the strong rubber odor
  • Features molded-in colors
  • Does not discolor or fade
  • Provides a snug fit that will not slip
  • Sold individually
Bestseller No. 7
Kojem Crossover Steering Kit Compatible with 1984-2001 Jeep Cherokee XJ 1993-1995 Jeep Grand Cherokee ZJ 1990-1992 Jeep Comanche MJ 1997-2006 Jeep Wrangler TJ/LJ Tie Rod Link Replacement for J0048827
  • Fitment: The crossover steering kit is compatible with 1984-2001 Jeep Cherokee XJ; compatible with 1993-1995 Jeep Grand Cherokee ZJ; compatible with 1990-1992 Jeep Comanche MJ; compatible with 1997-2006 Jeep Wrangler TJ/ LJ. Please confirm the fitment of the product before purchasing.
  • Material: Made of high quality steel for excellent strength and durability, which is impact-resistance and not easy to rust, ensuring a long-lasting usage for outdoor performance.
  • Feature: This crossover steering kit is an easy bolt-on solution to prevent link damaged and tie rod ends broken due to the use of larger tires.
  • Package Include: 1 x Crossover Steering Kit, including 2 x steering bars and hardware.
  • Installation: Easy bolt-on installation. Direct replace your previous steering bars. Instruction is NOT included. Professional installation is always recommended.
SaleBestseller No. 8
Plasticolor 006712R01 Steering Wheel Cover compatable with Jeep Wrangler
  • Only Officially Licensed Jeep Wrangler steering wheel cover made from actual Neoprene material
  • Wrangler is beautifully stitched in three places along wheel circumference
  • Steering wheel cover is perfect for any standard size steering wheel that measures from 14.5”-15.5” inches across
  • Made for durability and style, this steering wheel cover boasts a comfortable feel and a sure grip
  • Slip-on design makes for easy installation
Bestseller No. 9
KEYOOG Lower Intermediate Steering Shaft Column Fit for 1987 1988 1989 1990 1991 1992 1993 1994 1995 Jeep Wrangler [ w/Power Steering ] 425-274 52007017 52007017AA 52007017AB 52007017AC
  • 【Premium Quality】Manufactured by OEM-approved and ISO-certified manufacturers, using high-quality materials to directly replace the original car equipment, 100% factory tested to ensure quality and durability.
  • 【Less Expensive】KEYOOG Steering Shaft Column have reasonable price and excellent quality. If you are looking for high quality Steering Shaft Column replacement products. KEYOOG will provide you with the best quality Steering Shaft Column at a very affordable price.
  • 【Trustworthy performance】 Built to meet thorough torsional, tensile, fatigue and other durability testing for reliable operation.
  • 【Quality assurance】 We provide a one-year warranty. We try to provide quality products and service to our customers. Any problem please feel free to contact us and you will get a satisfactory solution.With nothing to worry about, try it today!
  • 【Compatibility】Before placing the order, please check your car model in the Amazon Fitment Filter System in the top left corner,Do not count on year make and model only,please view compatability tab including the notes,or send us a message to make sure it matches exactly.
Bestseller No. 10
Steering Stabilizer Tie Rod Clamp and Steering Stabilizer Relocation Bolt Fit for 2007-2022 Jeep Wrangler JK JKU JL JLU & Jeep Gladiator JT Aftermarket Tie Rod with 1-1/2" OD Tubing
  • FITMENT: Fit for 2007-2022 Jeep Wrangler JK JKU JL JLU & Jeep Gladiator JT Aftermarket Tie Rod with 1.5 inch OD tubing
  • MATERIAL: High quality steel stud and CNC machined steel clamp with blackening surface treatment have excellent mechanical and physical properties, good in corrosion resistance and durability
  • APPLICATION: This kit takes the steering stabilizer and moves it up for improved clearance and to reduce damage to the stabilizer shaft or body
  • FEATURES: Steering stabilizer relocation kit repositions the steering stabilizer to reduce tie rod roll, low profile stabilizer mounting stud prevents interference with upgraded steering components. 100% bolt on components assure a trouble free installation
  • 100% SATISFACTION GUARANTEE: We aim to give our customers the best products and services. If you're not 100% satisfied with our item, simply return it for a full refund in 30 days. Premium Support & 12-Month Warranty

Last update on 2024-01-30 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.

Leave a Comment

Share to...
