NUMBER: 05-005-03
GROUP: Brakes
DATE: Sept. 12, 2003
SUBJECT:
Creaking/Squeaking Sound From Brake Pedal During Actuation
OVERVIEW:
This bulletin involves lubricating the brake pedal return spring.
MODELS:
| 2004 | (CS) | Pacifica |
NOTE:Thisbulletin appliestovehicles builtonorbefore March28, 2003(MDH 0328XX).
SYMPTOM/CONDITION:
The vehicle operator may describe a creaking/squeaking sound from the brake pedal when applying the brakes during normal light to moderate braking.
DIAGNOSIS:
If the vehicle exhibits the Symptom/Condition, inspect the brake pedal return spring for presence of grease. If grease is not present or if the spring is not fully covered with grease, perform the Repair Procedure.
PARTSREQUIRED:
| Qty. | Part No. | Description |
|---|---|---|
| AR | 05083149AA | Grease, Wheel Bearing/Multi-Purpose
(MS 6560) 1 tub/tube will service multiple vehicles |
| or | ||
| 05083150AA |
REPAIRPROCEDURE:
- Access the brake pedal return spring.
- Apply approximately 5 to 8 grams (1/8 to 1/4 oz.), of p/n 05083149AA or 05083150AA Wheel Bearing/Multi-Purpose Grease to the spring and spread evenly around the entire spring.
- Actuate the brake pedal 5-10 times to assist the grease in penetrating within the spring coils.
POLICY:
Reimbursable within the provisions of the warranty.
TIMEALLOWANCE:
| Labor Operation No: | Description | Amount | |
|---|---|---|---|
| 05-50-04-90 | Spring, Brake Pedal Return – Lubricate | 0.2 Hrs. | |
FAILURECODE:
| 68 | Noisy |
