January 24, 2020 NHTSA CAMPAIGN NUMBER: 20V042000

Lower Control Arm May Separate from Axle

The improper weld may allow the lower control arm to separate from the axle which can increase the risk of a crash.



NHTSA Campaign Number: 20V042

Manufacturer Chrysler (FCA US LLC)

Components SUSPENSION

Potential Number of Units Affected 3,005



Summary

Chrysler (FCA US LLC) is recalling certain 2020 Jeep Wrangler vehicles. The left side lower control arm bracket and weld may not be correctly positioned.



Remedy

Chrysler will notify owners, and dealers will inspect the front axles, replacing them as necessary, free of charge. The recall began February 27, 2020. Owners may contact Chrysler customer service at 1-800-853-1403. Chrysler’s number for this recall is W01.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Vehicle has a Recall




February 2020

Dealer Service Instructions for:

Safety Recall W01 / NHTSA 20V-042 Front Axle Bracket



Remedy Available

2020 (JL) Jeep Wrangler



NOTE:  Some vehicles above may have been identified as not involved in this recall and therefore have been excluded from this recall.



IMPORTANT:  Some of the involved vehicles may be in dealer new vehicle inventory.  Federal law requires you to complete this recall service on these vehicles before retail delivery.  Dealers should also consider this requirement to apply to used vehicle inventory and should perform this recall on vehicles in for service.  Involved vehicles can be determined by using the VIP inquiry process.



Subject

The front axle bracket on about 3,449 of the above vehicles may have been built with a front axle left side lower control arm bracket, that may not have been in the correct location during the welding process. An off location weld may allow the lower control arm to separate from the axle. A separation of the bracket from the axle may cause a reduction in directional control and/or allow the lower control arm bracket to hit the ground while driving. This condition could cause a crash without prior warning.



Repair

Follow section A. Inspection procedure below.



Alternate Transportation

Dealers should attempt to minimize customer inconvenience by placing the owner in a loaner vehicle if inspection determines that repair is required and the vehicle must be held overnight.



Parts Information

All dealers will have the parts provided to repair the vehicle when the customer care representative reviews and approves the submitted photos and determines that repair is required.



Parts Return

No parts return required for this campaign.



Special Tools

The following special tool is required to perform this repair:

9360 Separator



Inspection Procedure

A. Inspection

  1. Raise and support the vehicle.



  1. Take a photo image of the left side axle control arm mounting bracket (Figure 1).



IMPORTANT: Photo image must  be clear and viewable in order to determine the quality of the weld. The images below are sample photo  images that are acceptable and NOT acceptable, any photos that are out of  focus or not clear  may require you to provide additional photos to  determine the quality of the weld.



  1. Forward the photos and the information below to: Weldinspect@dana.com



  • Only one Vehicle Identification Number (VIN) per Email



  • Enter ONLY ONE VIN in email subject line



  • Photos of the left axle bracket weld



  • Dealership Name, Code, Address, Contact Name, Phone Number and Email Address



Inspection Procedure [Continued]

A customer care representative will review the quality of the axle bracket weld and respond within 24 hours, with a determination of the welds are being acceptable or Front Axle replacement is required.

If the customer care representative determines that a Front Axle replacement is required, all the required repair parts will be shipped to the dealer information provided. Dealers are advised to provide a loaner vehicle to the customer if inspection determines that the vehicle must be held for repair.



Service Procedure

B. Front Axle Removal Procedure

  1. Disconnect the negative battery cable.



  1. Raise and support the vehicle.



  1. Remove both front wheel and tire assemblies.



  1. Position and secure a suitable jack to the axle.



  1. Remove the front driveshaft to pinion flange bolts and DISCARD (Figure 3).



  1. Remove front driveshaft from front differential pinion and secure out of the way using a bungee or       suitable strap (Figure 3).



NOTE: Do not allow the front driveshaft to hang.



  1. Using a pick unlock the TruLok wire harness connector, then disconnect from the axle module, and disengage the wiring harness clip from the front axle (Figure 4).



  1. Disconnect the axle vent hose (Figure 5).



  1. Remove the front caliper adapter bolts and front calipers as an assembly (Figure 6).



CAUTION: Never allow the disc brake caliper to hang from the brake hose. Damage to the brake hose will result. Provide a suitable support to hang the caliper securely.



  1. Remove the front rotor screws (Figure 7).



  1. Remove both front brake rotors (Figure 7).



  1. Remove the three brake rotor splash shield bolts and remove the splash shields (Figure 8).



  1. Clean the wheel speed sensor and surrounding area with shop towel before removing the speed sensor and DISCARD the bolt (Figure 9).



  1. Remove the brake hose mounting fastener on the coil spring pad (Figure 10).



  1. Remove the brake hose mounting fastener on the on the steering knuckle (Figure 11).



  1. Remove the brake hose mounting fastener on the on the lower control arm (Figure 12).



  1. Remove the stabilizer bar link lower bolts and nuts (Figure 13).



  1. Remove and DISCARD the right drag link outer nut (Figure 14).



  1. Separate the drag link from the steering knuckle using special tool 9360 Separator  (Figure 14).



  1. Remove and DISCARD the tie rod nuts (Figure 14).



  1. Separate the tie rods from the steering knuckle using special tool 9360 Separator (Figure 14).



  1. Remove the steering damper nut and bolt from the axle bracket (Figure 15).



NOTE: Do not remove the outer (Passengers Side) steering damper fasteners.



  1. Set the drag link assembly aside.



  1. Remove the track bar axle bolt and flag nut from the axle bracket.



  1. Remove upper control arms bolts and nuts from the axle brackets then move control arms from axle brackets (Figure 16).



  1. Loosen the front lower control arm nuts on both sides (Figure 16).



  1. Place a mark on the upper and lower coil spring Isolator, coil and coil seat, for reinstalling reference (Figure 17).



NOTE: It is important that the Coil Springs, and Isolators are installed in their correct orientation relative to the axle, failure to install them correctly will result in premature Coil Spring damage.



  1. Lower axle enough to remove coil springs from axle.



  1. Remove lower control arm bolts (Figure 16).



  1. Remove the lower shock absorber bolts, from the axle brackets.



  1. Carefully lower the front axle from vehicle.



  1. Proceed to section Front Axle Installation Procedure.



C. Front Axle Installation Procedure

CAUTION: The weight of the vehicle must be supported by the springs before control arms and track bar fasteners are tightened. Failure to follow these instructions will result in damage to the bushings.



  1. Transfer the lower coil spring pads onto the NEW front axle.



  1. Replace the left front lower control arm and hand sta rt the NEW bolt and nut tighten to 100N·m plus 65° (74ft.lbs.) plus 65°.



  1. Position and secure a suitable jack to the NEW front axle.



  1. Position the NEW front axle under the vehicle.



  1. Partially raise the axle.



  1. Attach the upper control arms onto the axle (Figure 16).



  1. Install upper control arm bolts and nuts and tighten to 100N·m plus 65° (74ft.lbs.) plus 65°. (Figure 16).



  1. Attach the lower control arms into the axle brackets (Figure 16).



  1. Install lower control arm bolts and nuts and tighten to 100N·m plus 50° (74ft.lbs.) plus 50°. (Figure 16).



  1. Install and align the coil springs to the marked upper coil pad (Figure 17).



  1. Position the coil spring on the lower axle pad such that the spring end is resting against the isolator’s spring stop.



  1. Verify that the upper and lower spring isolators are seated properly.



NOTE: It is important that the Coil Springs, and Isolators are installed  in their correct orientation relative to the axle, failure to install them  correctly will result in premature Coil Spring damage.



NOTE: Observe spring as the axle is raised into position.  The coil spring may catch the edge of isolator if it is not properly seated.



  1. Raise the front axle into position until the spring seats in the upper mount.



  1. Install shock absorbers on the axle brackets, insert the shock absorber bolt through hole and tighten to 100N·m (74ft. lbs.).



NOTE: Brake hose must be positioned in front of the shock absorber.



  1. Install the track bar into the axle bracket.



  1. Install the track bar bolt and flag nut and tighten to 70 N·m plus 155° (52ft. lbs.) plus 155°.



  1. Install drag link into the right steering knuckle (Figure 14).



  1. Install a NEW drag link nut and tighten to 40N·m plus 125° (59ft. lbs. plus 125°) (Figure 14).



  1. Install the steering damper bolt through the axle bracket and start it a few threads into the flag nut (Figure 15).



  1. Tighten the steering damper bolt and flag nut to 80N·m (59ft. lbs.).



  1. Insert the tie rod ends into the right and left steering knuckles (Figure 14).



NOTE: Hold the end of the ball stud with a wrench when removing or installing the nuts to prevent damage to the tie rod.



  1. Install NEW tie rod end nuts and tighten to 64N·m (47ft. lbs.).



  1. Install stabilizer bar links on axle brackets then install the nuts and tighten to 93N·m (69ft. lbs.) (Figure 13).



  1. Position the brake hose to the lower control arm mounting stud and tighten the nut to18 N·m (13ft.lbs.) (Figure 12).



  1. Position the brake hose bracket to the axle spring seat and install the bolt and tighten to 11 N·m (8ft.lbs.) (Figure 10).



  1. Position the brake hose wire form to the steering knuckle and install the bolt and tighten to 25 N·m (18ft.lbs.) (Figure 11).



NOTE: Brake Hose wire form must be inserted into the retainer hole to lock into position.



  1. Apply light coat of wheel bearing grease to the wheel speed sensors and insert the front wheel speed sensors in to the hub and bearing.



  1. Install NEW front wheel speed sensors bolts and tighten to 7N·m (62In. lbs.) (Figure 9).



  1. Install the splash shields and tighten the bolts to 11N·m (8ft. lbs.) (93In lbs.) (Figure 8).



  1. Position the rotor over the wheel studs and against the hub (Figure 7).



  1. Install the front rotor screw and tighten to 20N·m (15ft. lbs.) (177 in. lbs.) (Figure 7).



  1. Install the front caliper adapter and front caliper assemblies (Figure 6).



  1. Install the two caliper adapter bolts per side and tighten to 200N·m (148ft. lbs.).



  1. Install the driveshaft with the axle flange and tighten the NEW bolts to 121N·m (89ft. lbs.) (Figure 3).



  1. Connect the Tru-Lok wire harness connector and the axle vent hose (Figure 4 and 5).



  1. If damaged replace the tie-strap on the Tru-Lok wiring harness.



  1. Remove the axle support and lower the vehicle.



  1. Install the wheel and tire assemblies and tighten the lug nuts to 176N·m (130ft. lbs.).



  1. Reconnect the negative battery cable.



CAUTION: The weight of the vehicle must be supported by the springs before control arms and track bar fasteners are tightened. Failure to follow these instructions will result in damage to the bushings.



  1. Perform wheel alignment.





Completion Reporting and Reimbursement

Claims for vehicles that have been serviced must be submitted on the DealerCONNECT Claim Entry Screen located on the Service tab.   Claims paid will be used by FCA to record recall service completions and provide dealer payments.



Use one of the following labor operation numbers and time allowances:

Labor Operation
Number
Time
Allowance
Submit Photos of Axle Bracket Weld 02-W0-11-81 0.3 hours
NOTE: Dealers are not to submit a claim with the above LOP until a customer care representative email response is provided, indicating the vehicle does not require an axle replacement.
Submit Photos and Replace Front Axle, Lower Control Arm and perform wheel Alignment 02-W0-11-82 3.1 hours
Floor Plan Reimbursement 95-95-95-97 Calculate See Below



Floor Plan Reimbursement

Floor Plan Reimbursement represents the vehicle’s average daily allowance (see table below) multiplied by the number of days the vehicle was in dealer inventory and not available for sale.  This reimbursement is limited to the number of days from the date of the stop sale to the date that the remedy was made available.  Note:  If the vehicle was received by your dealership (KZX date) AFTER the stop sale date, you will use the KZX date instead of the stop sale date.   For this Recall, the stop sale was initiated on 01/31/2020 and the remedy was made available on 02/27/2020, therefore, the number of days cannot exceed 26days.



Vehicle Average Daily Allowance
2020 (JL) Jeep® Wrangler



NOTE:  See the Warranty Administration Manual, Recall Claim Processing Section, for complete recall claim processing instructions.



Dealer Notification

To view this notification on DealerCONNECT, select “Global Recall System” on the Service tab, then click on the description of this notification.



Owner Notification and Service Scheduling

All involved vehicle owners known to FCA are being notified of the service requirement by first class mail.  They are requested to schedule appointments for this service with their dealers.  A generic copy of the owner letter is attached.



Vehicle Lists, Global Recall System, VIP and Dealer Follow Up

All involved vehicles have been entered into the DealerCONNECT Global Recall System (GRS) and Vehicle Information Plus (VIP) for dealer inquiry as needed.

GRS provides involved dealers with an updated VIN list of their incomplete vehicles.  The owner’s name, address and phone number are listed if known. Completed vehicles are removed from GRS within several days of repair claim submission.

To use this system, click on the “Service”  tab and then click on “Global Recall System.”  Your dealer’s VIN list for each recall displayed can be sorted by: those vehicles that were unsold at recall launch, those with a phone number, city, zip code, or VIN sequence.

Dealers must perform this repair on all unsold vehicles before retail delivery. Dealers should also use the VIN list to follow up with all owners to schedule appointments for this repair.

Recall VIN lists may contain confidential, restricted owner name and address information that was obtained from the Department of Motor Vehicles of various states.  Use of this information is permitted for this recall only and is strictly prohibited from all other use.



Additional Information

If you have any questions or need assistance in completing this action, please contact your Service and Parts District Manager.

Customer Services / Field Operations

FCA US LLC




This notice applies to your vehicle,

 [Model Year and Model]  VIN XXXXXXXXXXXXXXXXX W01/NHTSA 20V-042



LOGO

VEHICLE PICTURE

YOUR SCHEDULING OPTIONS



  1. RECOMMENDED OPTION Call your authorized Chrysler / Dodge / Jeep® / RAM Dealership
  1. Call the FCA Recall Assistance Center at 1-800-853-1403. An agent can confirm part availability and help schedule an appointment
  1. Visit recalls.mopar.com, scan the QR code below, or download the Mopar Owner’s Companion App.



QR Code



Get access to recall notifications, locate your nearest dealer, and more through this website or Mopar Owner’s Companion App. You will be asked to provide your Vehicle Identification Number (VIN) to protect and verify your identity. The last eight characters of your VIN are provided above.



DEALERSHIP INSTRUCTIONS

Please reference Safety Recall W01.


IMPORTANT SAFETY RECALL

Front Axle Bracket

Dear [Name],



This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.

FCA US has decided that a defect, which relates to motor vehicle safety, exists in certain [2020 (JL) Jeep® Wrangler] vehicles.

It is extremely important to take steps now to repair your vehicle to ensure the safety of you and your passengers.



WHY DOES MY VEHICLE NEED REPAIRS?

Your vehicle [1] may have been built with a front axle left side lower control arm bracket that may not have been in the correct location during the welding process. An off location weld may allow the lower control arm to separate from the axle. A separation of the bracket from the axle, may cause a reduction in directional control and/or allow the lower control arm bracket to hit the ground while driving. This condition could cause a crash without prior warning.



HOW DO I RESOLVE THIS IMPORTANT SAFETY ISSUE?

FCA US will repair your vehicle [2] free of charge (parts and labor).  To do this, your dealer will inspect the quality of the axle bracket weld and replace the front axle and left side lower control arm if needed. The estimated repair time is about 4 hours. In addition, your dealer will require your vehicle for proper check-in, preparation, and check-out during your visit, which may require more time. Your time is important to us, so we recommend that you schedule a service appointment to minimize your inconvenience. Please bring this letter with you to your dealership.



TO SCHEDULE YOUR FREE REPAIR,
CALL YOUR CHRYSLER, DODGE, JEEP OR RAM DEALER TODAY



WHAT IF I ALREADY PAID TO HAVE THIS REPAIR COMPLETED?

If you have already experienced this specific condition and have paid to have it repaired, you may visit www.fcarecallreimbursement.com to submit your reimbursement request online. [3] Once we receive and verify the required documents, reimbursement will be sent to you within 60 days.  If you have had previous repairs performed and/or already received reimbursement, you may still need to have the recall repair performed.



We apologize for any inconvenience, but are sincerely concerned about your safety.  Thank you for your attention to this important matter.

Customer Assistance/Field Operations

FCA US LLC


Mr. Mrs. Customer
1234 Main Street
Hometown, MI 48371

[1] If you no longer own this vehicle, please help us update our records. Call the FCA Recall Assistance Center at 1-800-853-1403 to update your information.

[2] If your dealer fails or is unable to remedy this defect without charge and within a reasonable time, you may submit a written complaint to the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave., S.E., Washington, DC  20590, or you can call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-4249153), or go to safercar.gov.

[3] You can also mail in your original receipts and proof of payment to the following address for reimbursement consideration: FCA Customer Assistance, P.O. Box 21-8004, Auburn Hills, MI 48321-8007, Attention: Recall Reimbursement.



Note to lessors receiving this recall notice: Federal regulation requires that you forward this recall notice to the lessee within 10 days.




01/25/2020



New Safety Recall Advanced Communication – W01



FCA US LLC (FCA US) has announced a safety recall on certain 2020 Model Year (JL) Jeep® Wrangler vehicles.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with a front axle left side lower control arm bracket that may not have been in the correct location during the welding process. An off location weld may allow the lower control arm to separate from the axle. A separation of the bracket from the axle may cause a reduction in directional control and/or allow the lower control arm bracket to hit the ground while driving. This condition could cause a crash without prior warning.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to inspect the quality of the axle bracket weld and replace the front axle and left side lower control arm if needed. Dealers will be notified of the launch of this safety recall by way of established communication methods.  This recall is estimated to launch in 1st Quarter of 2020.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.



Customer Services Field Operations

FCA US LLC




01/31/2020



New Safety Recall Advanced Communication – W01



FCA US LLC (FCA US) has announced a safety recall on certain 2020 Model Year (JL) Jeep® Wrangler vehicles.



VINs identified as being involved in this campaign are currently live and searchable. Stop sale is in effect for the above-identified vehicles.



Vehicles impacted by a stop sale are eligible for reimbursement allowance through the Recall Floorplan Reimbursement Policy (RFPRP), which can be requested upon recall claim submission.



IMPORTANT:  Some of the involved vehicles may be in dealer new vehicleinventory.  Federal law requires you to complete this recall service on thesevehicles before retail delivery.  Violation of this requirement by a dealer couldresult in a civil penalty of up to $21,000 per vehicle.  Involved vehicles can be determined by using the VIP inquiry process.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with a front axle left side lower control arm bracket that may not have been in the correct location during the welding process. An off location weld may allow the lower control arm to separate from the axle. A separation of the bracket from the axle may cause a reduction in directional control and/or allow the lower control arm bracket to hit the ground while. This condition could cause a crash without prior warning.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to inspect the quality of the axle bracket weld and replace the front axle and left side lower control arm if needed. Dealers will be notified of the launch of this safety recall by way of established communication methods.  This recall is estimated to launch in 1st Quarter of 2020.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.



Customer Services Field Operations

FCA US LLC




1 Affected Product

Vehicle

MAKE MODEL YEAR
JEEP WRANGLER 2020




11 Associated Documents

Remedy Instructions and TSB

RCRIT-20V042-5504.pdf 2031.039KB

RCRIT-20V042-5504




ISSUED Owner Notification Letter(Part 577)

RCONL-20V042-2985.pdf 517.561KB

RCONL-20V042-2985




Recall Acknowledgement

RCAK-20V042-7527.pdf 244.157KB

RCAK-20V042-7527




Manufacturer Notices(to Dealers,etc)

RCMN-20V042-1570.pdf 97.115KB

RCMN-20V042-1570




Defect Notice 573 Report

RCLRPT-20V042-9046.PDF 214.474KB

RCLRPT-20V042-9046




Recall Quarterly Report #1, 2020-1

RCLQRT-20V042-5738.PDF 211.14KB

RCLQRT-20V042-5738




Recall Quarterly Report #2, 2020-2

RCLQRT-20V042-6683.PDF 211.242KB

RCLQRT-20V042-6683




Manufacturer Notices(to Dealers,etc)

RCMN-20V042-6952.pdf 100.127KB

RCMN-20V042-6952




Recall Quarterly Report #3, 2020-3

RCLQRT-20V042-1024.PDF 211.33KB

RCLQRT-20V042-1024




ISSUED Renotification Notice

RCRN-20V042-2957.pdf 138.038KB

RCRN-20V042-2957




Recall Quarterly Report #4, 2020-4

RCLQRT-20V042-3514.PDF 211.445KB

RCLQRT-20V042-3514




Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=20V042&docType=RCL






SaleBestseller No. 1
Valvoline SynPower SAE 75W-90 Full Synthetic Gear Oil 1 QT
  • Formulated to maintain excellent low temperature fluid protection
  • Helps provide outstanding thermal stability for cleanliness and longer service life
  • Contains special additives to assist in protecting gear teeth from rust and corrosion and reduce chattering in limited-slip differentials
  • Recommended for conventional and limited slip differentials and non-synchronized manual transmissions where API GL-5 or API GL-4 fluid is specificed
Bestseller No. 2
Mobil1 1043611 Full Synthetic Gear Lubricant, 75W-90 Quart 6 PK
  • Mobil 1 Synthetic Gear Lube LS is a supreme performance, synthetic, multipurpose, automotive gear lubricant
  • Meet or exceed the highest level of performance requirements of many modern passenger vehicles – including limited slip applications
  • Helps protect against thermal and oxidative degradation, wear and corrosion, and viscosity loss associated with premature shearing
  • Promotes outstanding power transfer performance - even in some of the most severe driving conditions
  • Sold as 6 pack
Bestseller No. 3
StarFire Full Synthetic 75W90 Gear Lubricant API GL-5,MT-1, 5 Gallon Pail
  • Provides excellent protection against wear under extreme pressure and high torque operation
  • High resistance to thermal breakdown
  • Helps prevent foaming, rust, and corrosion
  • Smooths and quiets operation
  • Protects against oxidative degradation
SaleBestseller No. 4
Mobil 1 104361-UNIT 75W-90 Synthetic Gear Lube - 1 Quart
  • Mobil 1 Synthetic Gear Lube Ls 75W-90 Mobil 1 Synthetic Gear Lube Ls 75W-90 Is A Supreme Performance, Synthetic, Multi-Purpose, Sae 75W-90 Automotive Gear Lubricant Designed To Meet The Highest Level Of Performance Requirements Of Modern Passenger Vehicles In All Types Of Operating Conditions, Including Limited Slip Applications, As Well As Delivering Outstanding Power Transfer Performance
  • Compared To Conventional Hypoid Gear Lubricants, Mobil 1 Synthetic Gear Lube Ls 75W-90 Performs Exceptionally Well Over A Wide Range Of Temperatures
  • Through Creativity, Productivity And Innovation - This Brand Continues To Develop The Finest Automotive Accessories
  • Model Number : 104361-UNIT
SaleBestseller No. 5
Lucas Oil 10048 SAE 75W-90 Synthetic Transmission and Differential Lubricant - 1 Gallon
  • Fit Type: Vehicle Specific
  • Package Dimensions: 31.75 H x 15.24 L x 15.24 W (centimeters)
  • Country of Origin : United States
  • Package Weight: 3.447 kilograms
Bestseller No. 6
Stens Lucas Oil 10047 SAE 75W-90 Synthetic Gear Oil/Transmission and Differential Lube - 1 Quart
  • Fit type: Vehicle Specific
  • Affordable solutions
  • Replaces OEM number: Lucas Oil: 10047
  • Excellent for use in limited-slip differentials
  • Packaging May Vary
Bestseller No. 7
Ultra1Plus SAE 75W-90 Synthetic Gear Oil API GL-5 (Gallon - 4 QTS)
  • LONGER EQUIPMENT LIFE: 75W-90 GL-5 gear oil is formulated with synthetic base oils and specialty performance additives to provide high-temperature thermal and oxidative stability in a wide range of operating conditions.
  • ENHANCED PERFORMANCE IN DIFFERENTIALS: Engineered with specific limited-slip (LS) additives, it eradicates chatter, ensuring seamless functionality in limited-slip differentials for smoother, efficient operation.
  • MAXIMUM GEAR PROTECTION: Extreme pressure anti-wear additives safeguard gear teeth from shock loading and high torque, ensuring prolonged gear life and reduced maintenance needs.
  • ALL-WEATHER RELIABILITY: U1P 75W-90 Gear Oil guarantees excellent cold temperature flow, ensuring reliable operation in diverse weather conditions.
  • COST-EFFECTIVE MAINTENANCE SOLUTION: Exceeding performance benchmarks, it minimizes maintenance costs and extends equipment lifespan, providing a cost-efficient solution for diverse applications.
Bestseller No. 8
Triax Synergy Gear MAX 75W-90 GL-5 Limited Slip, Ultra Long Drain 500k Miles, Manual Transmission, Gear/Differential Lubricant (1 Gallon)
  • EXTREME DRAIN INTERVALS - 500,000 miles for heavy duty trucks and passenger cars. 750,000 miles for Class 8 highway trucks.
  • PROFESSIONAL GRADE: Unrivaled shear stability and longevity. Meets and exceeds API GL-5 and Limited Slip requirements and a very wide range of specifications across multiple OEMs.
  • EXCELLENT WEAR CONTROL - Up to 62% less wear vs OEM Specifications across various standards. EXCEPTIONAL LOAD BEARING CAPACITY - Exceeds the highest load test rating, Stage 14.
  • WIDE RANGE OF APPLICATIONS - Hypoid and Ring Gears, Differentials, Limited Slip - Heavy Duty Highway, Passenger Cars, Heavy Duty Off-Road, Racing / Drifting. Will not shear under extreme torque. Features exceptional power transfer under extreme conditions. GREATLY EXCEEDS EP AND AW TESTS FZG AND L-37 - Proven protection far beyond spec requirements, delivers excellent EP (extreme pressure) and AW (anti-wear) performance in a wide range of LS and NON-LS gear systems, with hypoid and other gears.
  • TRUE SYNTHETIC WITH PAO - This is a true synthetic formulation with PAO base oil. Dont be fooled by cheap products which advertise themselves as Synthetics but have a VI Index below 160 and freeze at -30F and a very limited specification range.
Bestseller No. 9
Bestseller No. 10
Lucas Oil 10046 SAE 80W-90 Heavy Duty Gear Oil - 1 Gallon
  • Contains extraordinary anti-wear and lubricity agents, ensuring exceptional protection against wear and reducing drag
  • Helps to control heat
  • Incorporates Lucas cutting-edge additive technology derived from top-rated Lucas Heavy Duty Oil Stabilizer, the number one supplemental oil in the heavy-duty industry
  • Available in 1 quart and 1 gallon bottle sizes

Last update on 2024-02-19 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.

Leave a Comment

Share to...
