NUMBER: 09-011-15
GROUP: Engine
DATE: September 19, 2015
SUBJECT:
Incorrect 6.4L Engine Oil Dipstick
OVERVIEW:
This bulletin involves installing the correct engine oil indicator (Dipstick).
MODELS:
| 2015 | (WK) | Jeep Grand Cherokee |
NOTE: This bulletin applies to vehicles built on or before June 12, 2015 (MDH 0612XX) equipped with 6.4L Engine (Sales Codes ESG).
SYMPTOM/CONDITION:
The customer and/or technician may notice after performing an oil change the Dipstick may indicate the oil was over filled. When changing the oil and filter, service information shows 7 quarts are required. After installing 7 quarts the Dipstick may indicate the engine is over filled by 1 quart.
DIAGNOSIS:
If the customer describes the symptom/condition listed above, perform the Repair Procedure.
PARTS REQUIRED:
| Qty. | Part No. | Description |
|---|---|---|
| 1 | 05038472AB | Indicator, Engine Oil Level (Dipstick) |
REPAIR PROCEDURE:
- Remove the Dipstick from the tube and look for the part number.
Fig. 1 Location Of The Part Number On The Dipstick
- Is part number 05038472AA on the Dipstick?
- Yes >>> Replace the Dipstick with part number 05038472AB.
- No >>> This bulletin does not pertain, perform normal diagnostics if needed.
NOTE: Check engine oil level and adjust if needed.
POLICY:
Reimbursable within the provisions of the warranty.
TIME ALLOWANCE:
| Labor Operation No: | Description | Skill Category | Amount |
|---|---|---|---|
| 09-60-40-95 | Indicator Engine Oil – Replace (0 – Introduction) | 8 – Engine Performance | 0.2 Hrs. |
FAILURE CODE:
| ZZ | Service Action |
