October 24, 2019 NHTSA CAMPAIGN NUMBER: 19V757000

EGR Cooler May Crack and Cause Fire

Combustion in the intake manifold can increase the risk of a fire.



NHTSA Campaign Number: 19V757

Manufacturer Chrysler (FCA US LLC)

Components ENGINE AND ENGINE COOLING

Potential Number of Units Affected 107,979



Summary

Chrysler (FCA US LLC) is recalling certain 2014-2019 Ram 1500 and 1500 Classic Pickup trucks equipped with 3.0L Eco Diesel engines. The Exhaust Gas Recirculation (EGR) cooler may crack and allow pre-heated vaporized coolant to enter the EGR system. This mixture may combust inside the intake manifold.



Remedy

Chrysler will notify owners, and dealers will replace the EGR cooler, free of charge. Dealers will also inspect and, as necessary, replace the intake manifold. The recall began April 16, 2020. Owners may contact Chrysler customer service at 1-800-853-1403. Chrysler’s number for this recall is VB1.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



Check if your Vehicle has a Recall




Revised July 2020

Dealer Service Instructions for:

Safety Recall VB1 / NHTSA 19V-757 Diesel EGR Cooler



NOTE: Added 2017 – 2019 Model Years to campaign



The Remedy is Available

2014 – 2019 (DS) Ram 1500 Pickup



NOTE:  This recall applies only to the above vehicles equipped with a 3.0L Eco Diesel Engine (sales code EXF).

NOTE:  Some vehicles above may have been identified as not involved in this recall and therefore have been excluded from this recall.



IMPORTANT:  Some of the involved vehicles may be in dealer new vehicle inventory.  Federal law requires you to complete this recall service on these vehicles before retail delivery.  Dealers should also consider this requirement to apply to used vehicle inventory and should perform this recall on vehicles in for service.  Involved vehicles can be determined by using the VIP inquiry process.



Subject

The Exhaust Gas Recirculation (EGR) cooler on about 158,241 of the above vehicles may be susceptible to thermal fatigue.  Thermal fatigue may cause the cooler to crack internally over time.  An EGR cooler with an internal crack will introduce pre-heated, vaporized coolant to the EGR system while the engine is running. In certain circumstances, this mixture interacts with other hydrocarbons and air in the system, potentially resulting in combustion within the intake manifold, which may lead to a vehicle fire.  A vehicle fire may increase the risk of injury to occupants and persons outside of the vehicle, as well as property damage.



Repair

Replace the EGR cooler assembly ONLY. If Malfunction Indicator Lamp (MIL) is illuminated, inspect vehicle for either or both P0299 and P2D2F DTCs.  If present, perform section B. Intake Manifold Inspection and Pressure Test. Replace Intake Manifold, if perforation is identified using test procedure.

NOTE: If a vehicle had a new Mopar provided replacement engine please inspect for a white or yellow mark on the front fuel pump cover (Figure Below). If a yellow or white mark is present it’s an indication the updated EGR cooler has been installed, NO EGR cooler replacement is necessary.



Alternate Transportation

Dealers should attempt to minimize customer inconvenience by placing the owner in a loaner vehicle if the vehicle must be held overnight.



Parts Information

Description Part Number
Kit, EGR Cooler Installation CSNDVB12AA
Each package contains the following components:
Description Quantity
Cooler Bushings with O-Rings 2
Gasket, ERG Tube 2
Nut 2
Bolt, Turbo to EGR Tube 2
O-Ring, Intake Support 2
Bolt, Torx Head 1



Description Part Number
Kit, EGR Cooler CSNDVB11AA
Each package contains the following components:
Description Quantity
Cooler, EGR 1
NOTE: In some instances, CSNDVB11AB level kit may be provided; either part is an acceptable repair part
Coolant, as required (MS12106) (MSQ of 4) (1 gallon services approximately 3 vehicles) 68163849AB Safety Recall VB1 - Diesel EGR Cooler - 2014-2019 Ram 1500 | small light
NOTE: The following parts below are required only for vehicles that FAIL section A inspection procedure.



Description Part Number
Kit, High Pressure Fuel Lines CSNDVB13AA
Each package contains the following components:
Description Quantity
Fuel Line, High Pressure 2
Fuel Lines 3



Description Part Number
Kit, Intake Manifold and Gaskets CSNDVB14AA
Each package contains the following components:
Description Quantity
Intake, Manifold 1



Parts Return

No parts return required for this campaign.



Special Tools

The following special tools are required to perform this repair:

  • NPN
wiTECH micro pod II
  • NPN
Laptop Computer
  • NPN
wiTECH Software
  • 2025400090
Remover-Installer, Fuel Rail Bolt
  • 2048002090
Adapter, Pressure Test
  • 2048001090
Adapter, Pressure Test
  • 399-550000
Uview Airlift Cooling System Refill or equivilant



Service Procedure

A. Inspection



  1. Start engine and observe if the “Malfunction Indicator Lamp” is illuminated.



a) Is the “Malfunction Indicator Lamp” (MIL)illuminated?



  • NO – proceed to section Replace EGR Cooler.



  • YES proceed to step 2.



  1. Connect the wiTECH micro pod II to the vehicle data link connector.



  1. Place the ignition in the “RUN” position.



  1. Open the wiTECH 2.0 website.



  1. Enter your “User id” and “Password” and your “Dealer Code”, then select “Sign in” at the bottom of the screen. Click “Accept”.



  1. From the “Vehicle Selection” screen, select the vehicle to be updated.



  1. From the “Topology” tab, select the “PCM” module icon.



  1. Click “View DTCs”.



  1. Does the vehicle have one or both of the following DTC’s below?



YES – Proceed to section B. Intake Manifold Inspection and Pressure Test

NO – Advise customer of any DTC(s) and proceed with section E. Replace EGR Cooler





B. Intake Manifold Inspection and Pressure Test



  1. Disconnect the negative battery cable (Figure 1).



  1. Remove the engine cover (Figure 1).

  1. Remove TMAP sensor (boost pressure sensor) from the back of the intake and inspect the tip for signs of melting (Figure 2 and Figure 3).

Does the sensor show signs of melting?



  1. Remove the Charge Air Cooler (CAC) hose from the turbocharger outlet (WK and pre 16MY DS) or from the resonator assembly (2016 and newer DS), and install Charge Air Cooler Pressure Test Adapter 2048002090 into the CAC hose (Figure 4).

  1. Install suitable air pressure regulator onto test adapter set to 20psi of air pressure (Figure 4).
  2. Attach shop air to pressure regulator and pressurize CAC system and intake manifold to 20 psi.
  3. Check system for any leaks. Especially around the intake manifold. You should be able to hear large amounts of air escaping from around or under the intake manifold if perforation is present.
  4. If leak can be heard, but not pinpointed to either the CAC or intake, disconnect the shop air supply from the pressure regulator, and disconnect the CAC hose from the EGR Air Flow Control Valve (intake throttle valve) (Figure 5).



  1. Install CAC Pressure Test Adapter 2048001090 into the CAC hose, and reconnect the shop air supply (Figure 5).



  1. Inspect the cooler, and all hoses for source of the leak. Was the leak isolated to the Intake Manifold?
  • Yes – Proceed to section Intake Manifold Removal.
  • No – Further diagnosis and repair are required. Repair as necessary per normal, published repair and warranty guidelines.





C. Intake Manifold Removal



  1. Remove the Crank Case Ventilation (CCV) hose from the oil vapor separator cover. (During removal of the CCV hose do NOT disconnect CCV hose at the Air Tube.) (Figure 6).



  1. Disconnect the (CCV) hose heater wire harness connector (Figure 7).



NOTE: Disconnecting the electrical connector is a blind operation, it’s located near the turbo air inlet elbow.



  1. Grasp the air housing sides and pull straight up and tilt to disconnect the air cleaner housing from the body studs (Figure 9).



  1. Loosen the air intake clamp at the turbocharger intake at the back of the engine and remove the turbocharger air intake tube (Figure 10 and Figure 11).



 NOTE: Air intake clamp loosening is a blind operation.



  1. Remove the right fuel injector silencer (Figure 10).



  1. Remove the nut securing the left Charge Air Cooler (CAC) hose (Figure 12).



  1. Release the retaining lock and disconnect the left CAC hose at the resonator (Figure 12).



  1. Release the retaining lock and disconnect the CAC hose from the air cooler (Figure 12).



  1. Release the retaining lock and disconnect the CAC hose from the turbocharger elbow and remove the hose (Figure 13).



  1. Remove the leftfuel injector silencer.



  1. Remove the EGR tube bolts (2) at the EGR cooler (Figure 14).



  1. Remove the EGR bolts (2) at the intake manifold (Figure 15).



  1. Remove the EGR tube and DISCARD the metal gasket (Figure 15).



  1. Disconnect the Turbo Manifold Absolute Pressure (TMAP) sensor wire harness connector.



  1. Disconnect the turbocharger outlet temperature sensor wire harness connector.



NOTE: It is recommended to use a 5-inch-long stem 5mm ball-end Hex Bit socket to assist in removing the turbocharger outlet elbow bolts.



  1. Remove the bolt that secures the fuel cross-over line to the intake manifold (Figure 17).



  1. Remove the fuel rail cross-over line and DISCARD the line.



  1. Remove the bolts (2) securing the wire harness loom (Figure 18).



  1. Remove the 4 bolts and the fuel injection pump blocker shield (Figure 19).



CAUTION: Before separating a Quick-Connect fitting, pay attention to what type of fitting is being used. This will prevent unnecessary fitting or fitting latch breakage.



CAUTION: The interior components (O-rings, clips) of quick-connect replace the complete fuel line (tube) assembly.  fittings are not serviced separately, but new plastic spacers and latches are available for some types. If service parts are not available, do not attempt to repair the damaged fitting or fuel line (tube). If repair is necessary,



  1. Pry up on the safety clip with a screwdriver.



  1. Slide the safety clip away from the quick-connect fitting while lifting the screwdriver and position aside.



  1. Insert the commercially available fuel line removal tool into the quick-connect fitting and release the internal latches.



  1. Disconnect the supply and return lines from the fuel manifold (Figure 20).



NOTE: Place a mark on one of the fuel lines and corresponding fitting location, to identify correct reinstallation location.



  1. Disconnect the fuel return line at the fuel rail.



  1. Disconnect the fuel injector return line (Figure 21).



  1. Remove the nut and position the fuel manifold aside.



  1. Unscrew the union nuts and remove the left side high pressure fuel supply tube.



  1. Disconnect the EGR Vacuum Solenoid harness electrical connector (Figure 22).



  1. Disconnect the vacuum lines.



  1. Disconnect the inlet air temperature sensor wire harness connector (Figure 23).



  1. Disconnect the wire harness connector next to EGR air flow control valve (Figure 24).



  1. Remove the bolts and position the EGR airflow control valve forward to access the wire harness connector (Figure 25).



  1. Disconnect the following left side wire harness connectors:



  1. Unscrew the union nuts and remove the 3 left side fuel tubes and DISCARD the fuel tubes.



  1. Install protective caps on the fuel injectors and the fuel rail.



  1. Disconnect the following right side wire harness connectors:



  1. Remove the fasteners securing the wire harness to right cylinder head cover and position aside the wire harness.



  1. Using a shop vacuum, vacuum around the perimeter of the intake manifold.



  1. Using the Remover-Installer, Fuel Rail Bolt 2025400090 remove the bolts and the left fuel rail (Figure 26).



  1. Remove the 11 bolts and the intake manifold.



Tip: Use shallow swivel socket to aid in bolt removal.



CAUTION: Do Not rest the intake manifold on the swirl valve actuator.

Care must be taken when handling the swirl valve assembly.



  1. Transfer the intake manifold wiring harness onto the NEW intake manifold (Figure 27).



  1. Continue to section D. Intake Manifold Installation.



D. Intake Manifold Installation.



  1. Clean the intake gasket sealing surfaces.



  1. Install the intake manifold and tighten the bolts finger tight.



  1. Using the tightening sequence shown, tighten the bolts to 12 N·m (9 ft. lbs.) (Figure 28).



NOTE: Fuel tubes are a one-time only use and must be replaced anytime they have been removed.



  1. Install the left side fuel rail.



a. Install the fuel rail. Using the Remover-Installer, Fuel Rail Bolt 2025400090, tighten the bolts to 25 N·m (18 ft. lbs.) (Figure 26).



  1. Position the wire harness to the engine and securely tighten the fasteners securing the wire harness to right cylinder head cover.

  1. Connect the following right side wire harness connectors:
  2. Install the engine wire harness assembly to the intake manifold and push down to seat the wire harness retainers, and tighten the bolts to 11 N·m (8 ft. lbs.) (Figure 18).



  1. Connect the following left side wire harness connectors:
  2. Remove the protective caps on the fuel injectors and the fuel rail.



NOTE: Use a backing wrench on the fuel injector when tightening the union nut.



NOTE: The fuel tubes are a one-time only use and must be replaced anytime they have been removed.



  1. Install the NEW left side fuel tubes and tighten the union nuts finger tight.



  • Tighten the union nuts at the fuel rail to 5 N·m (44 in. lbs.) plus an additional 75 degrees turn.



  • Tighten the union nuts at the fuel injectors to 11 N·m (8ft. lbs.) plus an additional 75 degrees turn.



NOTE: Use a backing wrench on the fuel injector when tightening the union nut.



WARNING:  Observe the following precautions when working on fuel systems: No sparks, open flames or smoking. Avoid inhaling and swallowing fuel.



Avoid eye and skin contact with fuel. Pour fuels only into suitable and appropriately marked containers. Wear protective clothing. Failure to observe these precautions may result in fire, explosion, property damage, and serious or fatal injury.



WARNING: High-pressure lines deliver diesel fuel under extreme pressure from the injection pump to the fuel injectors. This may be as high as 2000 bar (29,008 psi). Use extreme caution when inspecting for high-pressure fuel leaks. Fuel under this amount of pressure can penetrate skin causing personal injury or death. Inspect for high-pressure fuel leaks with a sheet of cardboard. Wear safety goggles and adequate protective clothing when servicing fuel system



  1. Position the EGR airflow control valve and connect the EGR airflow control valve harness connector.



  1. Install the EGR airflow control valve and tighten the bolts to (9 N·m 80 in. lbs.). (Figure 25).



  1. Connect the inlet air temperature sensor wire harness connector (Figure 23).



  1. Install the EGR bypass solenoid and tighten the bolts to 9 N·m (80 in. lbs.).



  1. Connect the wire harness connector next to EGR air flow control valve (Figure 24).
  2. Install the NEW left high pressure fuel tube and tighten union nuts finger tight:
    • Tighten the union nut at the fuel rail to 5 N·m (44 in. lbs.) plus an additional 75 degrees turn.
    • Tighten the union nut at the fuel pump to 11 N·m (8 ft. lbs.) plus an additional 75 degrees turn.



NOTE: Fuel tubes are a one-time only use and must be replaced anytime they have been removed.



  1. Install the fuel manifold and tighten the nut to 8 N·m (71 in. lbs.) (Figure 21).



  1. Connect the fuel injector return line (Figure 21).



  1. Connect the fuel return line at the fuel rail (Figure 21).



  1. Connect the supply and return lines to the fuel manifold and engage the safety clips (Figure 20).
  2. Install the fuel injection pump blocker shield and tighten the bolts to 25 N·m (18 ft. lbs.) (Figure 19.)
  3. Install the NEW cross-over fuel tube and tighten the union nuts finger tight (Figure 17).
    • Tighten the union nuts to 5 N·m (44 in. lbs.) plus an additional 75 degrees turn.
  4. Install the bolt securing the fuel cross over line and tighten to 11 N·m (8 ft. lbs.) (Figure 17).



  1. Be sure the O-ring seal is seated in the turbocharger outlet flange.



  1. Install the turbocharger outlet elbow and tighten the bolts to 11 N·m (8 ft. lbs.).



  1. Connect the outlet temperature sensor wire harness connector.



  1. Connect the boost pressure sensor wire harness connector (TMAP).



  1. Install the left fuel injector silencer.



  1. Connect the Charge Air Cooler (CAC) hose to the turbocharger elbow (Figure 13).



  1. Install the CAC hose to the resonator and engage the retaining lock (Figure 12).



  1. Install the nut securing the left CAC hose and tighten securely (Figure 12).



  1. Proceed to section Replace EGR Cooler





E. Replace EGR Cooler



  1. Disconnect and isolate the negative battery cable.



  1. Raise and support the vehicle.



  1. If equipped: remove the front skid plate.
  2. Use the following steps to drain the cooling system.



a. Position a clean drain pan under draincock location.

b. Open radiator draincock located at the Figure 29 – Radiator Draincock lower left side of radiator. Turn draincock counterclockwise until it stops and allow to drain (Figure 29).

c. Lower the vehicle.

d. Remove coolant pressure cap (Figure 30).



WARNING: Make sure engine cooling system is cool before servicing. Do not remove any clamps or hoses, pressure cap, or open the radiator draincock. When the system is hot and under pressure serious burns from coolant can occur.



NOTE: DO NOT WASTE reusable coolant. If the solution is clean, drain the coolant into a clean container for reuse.



NOTE: When servicing the cooling system, it is essential that coolant does not drip onto the accessory drive belts and/or pulleys. Shield the belts with shop towels before working on the cooling system. If coolant contacts the belts or pulleys, flush both with clean water.



  1. Remove the engine cover (Figure 30).



  1. Loosen clamp and remove intake air tube from MAF sensor (Figure 31).



  1. Loosen clamp and remove intake air tube from turbocharger. (Figure 32 and 33).



  1. Remove the right fuel injector silencer (Figure 32).



  1. Remove the (2) EGR tube bolts (Figure 34).



  1. Remove the (2) bolts at the intake manifold and the EGR tube (Figure 35).



  1. Remove and discard the metal gasket (Figure 34).



  1. Disconnect EGR temperature sensor wire harness connector (Figure 36).



  1. Disconnect the EGR valve wire harness connector (Figure 37).



  1. Disconnect the EGR cooler vacuum bypass hose (Figure 38).



  1. Remove the bolts and the tube from the EGR cooler (Figure 39).



  1. Remove the top bolt at the rear of the EGR cooler bypass valve support bracket (Figure 40).



NOTE: Do not remove the lower bolt from the support bracket.



  1. Remove the two nuts and bolt and the EGR cooler assembly (Figure 41).



  1. Remove and DISCARD the O-ring seals (Figure 42).



  1. Clean the O-ring sealing surfaces.



  1. Install NEW O-ring seals onto the EGR cooler and mounting bracket (Figure 42).



  1. Lubricate the (2) NEW O-ring seals attached to EGR cooler bushings and install them onto the EGR cooler ports.



NOTE: Only use clean coolant to lubricate the O-rings and avoid using any petroleum products on the O-rings.



  1. Install the NEW EGR cooler assembly and tighten the nuts and bolt to 25 N·m (18 ft.lbs.).



  1. Install the NEW bolt at the rear EGR cooler bypass valve support bracket and tighten to 25 N·m (18 ft. lbs.) (Figure 40).



  1. Install the exhaust tube and NEW metal gasket and tighten the bolts to 25 N·m (18 ft. lbs.) (Figure 39).



  1. Connect the EGR cooler vacuum bypass hose.



IMPORTANT

NOTE: The rubber sleeve on the vacuum hose must be inserted to the full depth of the slot on top of the vacuum actuator. To facilitate insertion use P80 or a similar lubricant (soapy water).



  1. Connect the EGR valve wire harness connector (Figure 37).



  1. Connect EGR temperature sensor wire harness connector (Figure 36).



  1. Using the following steps install the EGR tube.



  1. Clean all gasket sealing areas.



  1. Install a NEW EGR tube adapter pipe metal gasket (Figure 34).



  1. Install the EGR tube to the intake manifold and tighten the bolts to 11 N·m (8 ft. lbs.).
  2. Install the EGR tube to the EGR cooler assembly and tighten the bolts to 25 N·m (18 ft. lbs.).



  1. Install the fuel injector silencer (Figure 32).



  1. Install the intake air tube onto turbocharger and securely tighten clamp (Figure 32).



  1. Install the intake air tube to MAF sensor and securely tighten clamp (Figure 31).



  1. Install the engine cover (Figure 30).



  1. Raise and support the vehicle.



  1. Tighten the radiator draincock (Figure 29).



  1. If equipped: Install the front skid plate and tighten the bolts to 18 N·m (13 ft. lbs.).



  1. Lower the vehicle.



  1. Connect the negative battery cable.



  1. Continue to section Fill the Cooling System.



F.  Fill the Cooling System



  1. Use the following steps to evacuate air and refill the cooling system.



a. Using Refractometer 8286 or equivalent, following the manufacturer’s instructions, test the coolant freeze point (Figure 43).



  • If the coolant tested is between -25°F and – 50°F (-31°C and -45°C) and is free of contamination, reuse the original the coolant.
  • If the coolant tested is contaminated, refill the cooling system with new coolant.
  • If the coolant tested is not between -25°F and – 50°F (-31°C and -45°C) and is free of contamination, use the chart below to add the appropriate amount of new coolant prior to completely refilling the cooling system with the remaining original coolant (Figure 44).



COOLANT ADJUSTMENT CHART TO MAINTAIN RECOMMENDED FREEZE POINT PROTECTION
Freeze Point (°F) vs. Percent Premix Coolant
EXAMPLE: FOR A VEHICLE WITH A SINGLE RADIATOR AND A -20°F FREEZE POINT, 4 QUARTS OF NEW PREMIXED COOLANT MUST REPLACE 4 QUARTS OF ORIGNAL COOLANT PRIOR TO COMPLETING THE REFILL PROCEDURE. Acceptable Concentrations
Freeze Point, °F1 +32 +25 +20 +15 +10 +5 0 -5  -10 -15 -20 -25 -30 -35 -50 -65 -75 -84
EG Content, vol% 0% 10% 16% 21% 25% 29% 33% 36% 39% 42% 44% 46% 48% 50% 55% 60% 65% 70%
Drain Coolant and Add New Premixed Coolant (Quarts)
Single Radiator 20 18 16 14 14 12 10 8 8 6 4 6 10 12
Dual Radiators 24 22 20 18 16 14 12 10 8 6 6 8 12 14
1)  The specified refractometer shows freeze point (FP) values down to ~-84°F.  For FPs below -84F (off the scale), replace all of the coolant with New Premixed Coolant. 2)  1 Gallon = 4 Quarts or 3.8 Liters



Figure 44 – Coolant Adjustment Chart



NOTE:  Evacuating or purging air from the cooling system involves the use of a pressurized air operated vacuum generator. The vacuum created allows for a quick and complete coolant refilling while removing any airlocks present in the system components.



WARNING:  Antifreeze is an ethylene glycol base coolant and is harmful if swallowed or inhaled. If swallowed, drink two glasses of water and induce vomiting. If inhaled, move to fresh air area. Seek medical attention immediately. Do not store in open or unmarked containers. Wash skin and clothing thoroughly after coming in contact with ethylene glycol. Keep out of reach of children. Dispose of glycol based coolant properly. Contact your dealer or government agency for location of collection center in your area. Do not open a cooling system when the engine is at operating temperature or hot under pressure; personal injury can result. Avoid radiator cooling fan when engine compartment related service is performed; personal injury can result.



WARNING: WEAR APPROPRIATE EYE AND HAND PROTECTION WHEN PERFORMING THIS PROCEDURE.



NOTE: The service area where this procedure is performed should have a minimum shop air requirement of 80 PSI (5.5 bar) and should be equipped control should be set to the heat position (ignition may need to be turned to  with an air dryer system.



NOTE: For best results, the radiator should be empty. The vehicle’s heater the on position but do not start the motor).



b. Refer to the Mopar Essential Tools and Service Equipment Tool, UView Airlift™ Cooling System  Refill 399-550000 or equivalent and follow tool’s operating manual for specific assembly steps.

c. Choose an appropriate adapter cone that will fit the vehicle’s radiator filler neck or reservoir tank.

d. Attach the adapter cone to the vacuum gauge.

e. Make sure the vacuum generator/venturi ball valve is closed and attach an airline hose (minimum shop air requirement of 80 PSI (5.5 bar) to the vacuum generator/venturi.

f. Position the adaptor cone/vacuum gauge assembly into the radiator filler neck or reservoir tank. Ensure that the adapter cone is sealed properly.

g. Connect the vacuum generator/venturi to the positioned adaptor cone/vacuum gauge assembly.

h. Open the vacuum generator/venturi ball valve.



NOTE: Do not bump or move the assembly as it may result in loss of vacuum. Some radiator overflow hoses may need to be clamped off to obtain vacuum.



i. Let the system run until the vacuum gauge shows a good vacuum through the cooling system. Refer to the tool’s operating manual for appropriate pressure readings.



NOTE:  If a strong vacuum is being created in the system, it is normal to see the radiator hoses collapse.



j. Close the vacuum generator/venturi ball valve.

k. Disconnect the vacuum generator/venturi and airline from the adaptor cone/vacuum gauge assembly.

l. Wait approximately 20 seconds, if the pressure readings do not move, the system has no leaks. If the pressure readings move, a leak could be present in the system and the cooling system should be checked for leaks and the procedure should be repeated.

m. Place the tool’s suction hose into the coolant’s container.



NOTE: Ensure there is a sufficient amount of coolant, mixed to the required strength/protection level available for use. For best results and to assist the refilling procedure, place the coolant container at the same height as the radiator filler neck. Always draw more coolant than required. If the coolant level is too low, it will pull air into the cooling system which could result in airlocks in the system.



n. Connect the tool’s suction hose to the adaptor cone/vacuum gauge assembly.

o. Open the suction hose’s ball valve to begin refilling the cooling system.

p. When the vacuum gauge reads zero, the system is filled.



NOTE: On some remote pressurized tanks, it is recommended to stop filling when the proper level is reached.



q. Close the suction hose’s ball valve and remove the suction hose from the adaptor cone/vacuum gauge assembly.

r. Remove the adaptor cone/vacuum gauge assembly from the radiator filler neck or reservoir tank.

s. With heater control unit in the HEAT position, operate the engine with container cap in place.

t. After engine has reached normal operating temperature, shut the engine off and allow it to cool. When engine is cooling down, coolant will be drawn into the radiator from the pressure container.

u. Add coolant to the recovery bottle/container as necessary. Only add coolant to the container when the engine is cold. Coolant level in a warm engine will be higher due to thermal expansion. Add necessary coolant to raise container level to the COLD MINIMUM mark after each cool down period.

v. Once the appropriate coolant level is achieved, attach the radiator cap or reservoir tank cap.



  1. Start and warm the engine until cooling fan comes on and check for leaks.



  1. Complete Proof of Corrections Form for California residents.



  1. Return the vehicle to the customer.



Complete Proof of Correction Form for California Residents

This recall is subject to the State of California Registration Renewal/Emissions Recall Enforcement Program.  Complete a Vehicle Emission Recall Proof of Correction Form (Form No. 81-016-1053) and supply it to vehicle owners residing in the state of California for proof that this recall has been performed when they renew the vehicle registration.

Process Steps to obtain the California Proof of Correction form:

  1. Access the “DealerCONNECT” website.
  2. Select the “Service” tab.
  3. Under the “Publications” heading, select the “ePublishing” link.
  4. Sign in using your Dealer Code and Password.
  5. Select the “Proof of Correction form”.



Completion Reporting and Reimbursement

Claims for vehicles that have been serviced must be submitted on the DealerCONNECT Claim Entry Screen located on the Service tab.   Claims paid will be used by FCA to record recall service completions and provide dealer payments.

Use one of the following labor operation numbers and time allowances:

Labor Operation
Number
Time
Allowance
Inspect Injection Pump Cover for Paint Mark 25-VB-11-81 0.0 hours
Check Malfunction Indicator Lamp (MIL) and Replace EGR Cooler 25-VB-11-82 1.7 hours
Check fault Codes, Pressure Test Charge Air Cooler System and Replace EGR Cooler 25-VB-11-83 1.9 hours
Check Fault Codes, Pressure Test Charge Air Cooler System, and Replace EGR Cooler and Intake Manifold 25-VB-11-84 4.8 hours
Related Operation
Handling Fee for Inspecting Paint Mark on Fuel Injection Pump Cover ONLY TO BE USED ON Service Engine Replacement to close recall. 95-23-30-57



NOTE:  See the Warranty Administration Manual, Recall Claim Processing Section, for complete recall claim processing instructions.



Dealer Notification

To view this notification on DealerCONNECT, select “Global Recall System” on the Service tab, then click on the description of this notification.



Owner Notification and Service Scheduling

All involved vehicle owners known to FCA are being notified of the service requirement by first class mail.  They are requested to schedule appointments for this service with their dealers.  A generic copy of the owner letter is attached.



Vehicle Lists, Global Recall System, VIP and Dealer Follow Up

All involved vehicles have been entered into the DealerCONNECT Global Recall System (GRS) and Vehicle Information Plus (VIP) for dealer inquiry as needed.



GRS provides involved dealers with an updated VIN list of their incomplete vehicles.  The owner’s name, address and phone number are listed if known.  Completed vehicles are removed from GRS within several days of repair claim submission.



To use this system, click on the “Service” tab and then click on “Global Recall System.”  Your dealer’s VIN list for each recall displayed can be sorted by: those vehicles that were unsold at recall launch, those with a phone number, city, zip code, or VIN sequence.



Dealers must perform this repair on all unsold vehicles before retail delivery. Dealers should also use the VIN list to follow up with all owners to schedule appointments for this repair.

Recall VIN lists may contain confidential, restricted owner name and address information that was obtained from the Department of Motor Vehicles of various states.  Use of this information is permitted for this recall only and is strictly prohibited from all other use.



Additional Information

If you have any questions or need assistance in completing this action, please contact your Service and Parts District Manager.

Customer Services / Field Operations

FCA US LLC




This notice applies to your vehicle,

 [Model Year and Model]  VIN XXXXXXXXXXXXXXXXX  VB1/NHTSA 19V-757



LOGO



VEHICLE PICTURE

YOUR SCHEDULING OPTIONS



  1. RECOMMENDED OPTION Call your authorized Chrysler / Dodge / Jeep® / RAM Dealership



  1. Call the FCA Recall Assistance Center at 1-800-853-1403. An agent can confirm part availability and help schedule an appointment



  1. Visit recalls.mopar.com, scan the QR code below, or download the Mopar Owner’s Companion App.



QR Code



Get access to recall notifications, locate your nearest dealer, and more through this website or Mopar Owner’s Companion App. You will be asked to provide your Vehicle Identification Number (VIN) to protect and verify your identity. The last eight characters of your VIN are provided above.



DEALERSHIP INSTRUCTIONS

Please reference Safety Recall VB1.




IMPORTANT SAFETY RECALL

Diesel EGR Cooler



Dear [Name],

This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.



FCA US has decided that a defect, which relates to motor vehicle safety, exists in certain [2014 through 2019 Model Year (DS) RAM 1500 Pickup] vehicles equipped with a 3.0L Eco Diesel engine.



It is extremely important to take steps now to repair your vehicle to ensure the safety of you and your passengers.



WHY DOES MY VEHICLE NEED REPAIRS?

The Exhaust Gas Recirculation (EGR) cooler on your vehicle [1] may be susceptible to thermal fatigue.  Thermal fatigue may cause the cooler to crack internally over time.  An EGR cooler with an internal crack will introduce pre-heated, vaporized coolant to the EGR system while the engine is running. In certain circumstances, this mixture interacts with other hydrocarbons and air in the system, potentially resulting in combustion within the intake manifold, which may lead to a vehicle fire.  A vehicle fire may increase the risk of injury to occupants and persons outside of the vehicle, as well as property damage.



HOW DO I RESOLVE THIS IMPORTANT SAFETY ISSUE?

FCA US will repair your vehicle [2] free of charge (parts and labor).  To do this, your dealer will replace the EGR cooler with a new EGR cooler that is not susceptible to thermal fatigue. In the event the intake manifold is damaged, the intake manifold will also be replaced. The estimated repair time is about 2 hours. However, additional time will be necessary if the Intake Manifold needs to be replaced. In addition, your dealer will require your vehicle for proper check-in, preparation, and check-out during your visit, which may require more time. Your time is important to us, so we recommend that you schedule a service appointment to minimize your inconvenience. Please bring this letter with you to your dealership.



TO SCHEDULE YOUR FREE REPAIR,
CALL YOUR CHRYSLER, DODGE, JEEP OR RAM DEALER TODAY



CALIFORNIA RESIDENTS

The State of California requires the completion of emission recall repairs prior to vehicle registration renewal.  Your dealer will provide you with a Vehicle Emission Recall Proof of Correction Form after the Emission Recall service is performed.  Be sure to save this form since the California Department of Motor Vehicles may require that you supply it as proof that the Emission Recall has been performed.

In order to ensure your full protection under the emissions warranty provisions, it is recommended that you have your (vehicle or engine) serviced as soon as possible. Failure to do so could be determined as lack of proper maintenance of your (vehicle or engine).



WHAT IF I ALREADY PAID TO HAVE THIS REPAIR COMPLETED?

If you have already experienced this specific condition and have paid to have it repaired, you may visit www.fcarecallreimbursement.com to submit your reimbursement request online. [3] Once we receive and verify the required documents, reimbursement will be sent to you within 60 days.  If you have had previous repairs performed and/or already received reimbursement, you may still need to have the recall repair performed.



We apologize for any inconvenience, but are sincerely concerned about your safety.  Thank you for your attention to this important matter.



Customer Assistance/Field Operations

FCA US LLC




Mr. Mrs. Customer
1234 Main Street
Hometown, MI 48371



[1] If you no longer own this vehicle, please help us update our records. Call the FCA Recall Assistance Center at 1-800-853-1403 to update your information.

[2] If your dealer fails or is unable to remedy this defect without charge and within a reasonable time, you may submit a written complaint to the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave., S.E., Washington, DC  20590, or you can call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-4249153), or go to safercar.gov.

[3] You can also mail in your original receipts and proof of payment to the following address for reimbursement consideration: FCA Customer Assistance, P.O. Box 21-8004, Auburn Hills, MI 48321-8007, Attention: Recall Reimbursement.



Note to lessors receiving this recall notice: Federal regulation requires that you forward this recall notice to the lessee within 10 days.




This notice applies to your vehicle,

[Model Year and Model]

VIN XXXXXXXXXXXXXXXXX

VB1/NHTSA 19V-757



LOGO

VEHICLE PICTURE

YOUR SCHEDULING OPTIONS

  1. Visit mopar.com to sign up for email or SMS notifications for when remedy parts become available. You will be asked to provide your Vehicle Identification Number (VIN), provided above
  2. Scan below using your smartphone or tablet to sign up to be notified when remedy parts become available
  1. Wait for FCA US to contact you again, by mail, with a follow-up recall notice when remedy parts are available
  2. Call the FCA Recall Assistance Center at 1-800-853-1403. An agent can sign you up to be notified when remedy parts become available, or answer any other questions you may have



DEALERSHIP INSTRUCTIONS

Please reference Safety Recall VB1.




IMPORTANT SAFETY RECALL

Diesel EGR Cooler



Dear [Name],

This notice is sent to you in accordance with the National Traffic and Motor Vehicle Safety Act.

FCA US has decided that a defect, which relates to motor vehicle safety, exists in certain [2014 through 2019 Model Year (DS) RAM 1500 Pickup] vehicles equipped with a 3.0L Eco Diesel engine.



WHY DOES MY VEHICLE NEED REPAIRS?

The Exhaust Gas Recirculation (EGR) cooler on your truck [1] may be susceptible to thermal fatigue.  Thermal fatigue may cause the cooler to crack internally over time.  An EGR cooler with an internal crack will introduce pre-heated, vaporized coolant to the EGR system while the engine is running. In certain circumstances, this mixture interacts with other hydrocarbons and air in the system, potentially resulting in combustion within the intake manifold, which may lead to a vehicle fire.  A vehicle fire may increase the risk of injury to occupants and persons outside of the vehicle, as well as property damage.



HOW DO I RESOLVE THIS IMPORTANT SAFETY ISSUE?

The remedy for this condition is not currently available. We are making every effort to finalize the remedy as quickly as possible, and will service your vehicle free of charge (parts and labor). In the interim, customers are advised to monitor their coolant levels; if consistently low, they are advised to contact their dealers.

FCA US will contact you again, by mail, with a follow-up recall notice when the remedy is available. Once you receive your follow-up notice, simply contact your Chrysler, Jeep®, Dodge or RAM dealer right away to schedule a service appointment [2]. Additional options for your next steps are included on the left side of this notification. We appreciate your patience.



WHAT IF I ALREADY PAID TO HAVE THIS REPAIR COMPLETED?

If you have already experienced this specific condition and have paid to have it repaired, you may visit www.fcarecallreimbursement.com to submit your reimbursement request online [3]. Once we receive and verify the required documents, reimbursement will be sent to you within 60 days. If you have had previous repairs performed and/or already received reimbursement, you may still need to have the recall repair performed.

We apologize for any inconvenience, but are sincerely concerned about your safety. Thank you for your attention to this important matter.

Customer Assistance/Field Operations  FCA US LLC



Mr. Mrs. Customer
1234 Main Street
Hometown, MI 48371



[1] If you no longer own this vehicle, please help us update our records. Call the FCA Recall Assistance Center at 1-800-853-1403 to update your information.

[2] If your dealer fails or is unable to remedy this defect without charge and within a reasonable time, you may submit a written complaint to the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave., S.E., Washington, DC 20590, or you can call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to safercar.gov.

[3] You can also mail in your original receipts and proof of payment to the following address for reimbursement consideration: FCA Customer Assistance, P.O. Box 218004, Auburn Hills, MI 48321-8007, Attention: Recall Reimbursement.

Note to lessors receiving this recall notice: Federal regulation requires that you forward this recall notice to the lessee within 10 days.




December 2019

SAFETY RECALL VB1: 2014-2019 DS 3.0L EGR Cooler Customer Handling

In the event that a customer contacts your dealership regarding concerns related to the VB1 Recall, please advise the customer that parts are currently being obtained and a Remedy is expected April 2020. Customers should also be advised to check their coolant level once every week. If coolant level is consistently below the cold fill line, please direct the customer to come to the Dealership for diagnosis immediately. Click HERE for a one pager that can be provided to the customer to assist with checking the coolant level.

When diagnosing the vehicle, place the customer in a loaner for their convenience. Vehicles should be repaired as per their current warranty coverage. Goodwill assistance should be provided for vehicles no longer under warranty for EGR Cooler replacements. If a customer needs their EGR Cooler replaced, order EGR Cooler part number 68483334AA and Bushing part number 68490221AA (2 required). Part supply is extremely limited. If additional parts are needed follow the order escalation process per the instructions HERE. If there is any issue using this process, please contact your Area Manager or Business Center immediately.

An EGR Cooler should only be replaced if the part has failed.

If the vehicle does not currently need any repairs and the customer is still concerned for their safety, please provide the customer with a loaner vehicle until such time that the remedy for the recall is available. Reimbursement will be provided for rental expenses at the current reimbursement rates per FCA Policy regardless of the vehicle’s current warranty coverage. If a customer is placed into a long term rental please inform your Area Manager.

FCA appreciates your support!




11/01/2019

New Safety Recall Advanced Communication – VB1



FCA US LLC (FCA US) has announced a safety recall on certain 2014 through 2019 Model Year (DS) RAM 1500 Pickup trucks equipped with a 3.0L Eco Diesel engine.



VINs identified as being involved in this campaign are currently live and searchable. Stop sale is in effect for the above-identified vehicles.



Vehicles impacted by a stop sale are eligible for reimbursement allowance through the Recall Floorplan Reimbursement Policy (RFPRP), which can be requested upon recall claim submission.



IMPORTANT:  Some of the involved vehicles may be in dealer new vehicle inventory.  Federal law requires you to complete this recall service on these vehicles before retail delivery.  Violation of this requirement by a dealer could result in a civil penalty of up to $21,000 per vehicle.  Involved vehicles can be determined by using the VIP inquiry process.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with Exhaust Gas Recirculation (EGR) coolers that are susceptible to thermal fatigue. Thermal fatigue may cause the cooler to crack internally over time.  An EGR cooler with an internal crack will introduce preheated, vaporized coolant to the EGR system while the engine is running. In certain circumstances, this mixture interacts with other hydrocarbons and air in the system, potentially resulting in combustion within the intake manifold, which may lead to a vehicle fire.  A vehicle fire may increase the risk of injury to occupants and persons outside of the vehicle, as well as property damage.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to repair the vehicles.  The remedy for this condition is not currently available.  Dealers will be notified of the launch of this safety recall by way of established communication methods.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.



Customer Services Field Operations

FCA US LLC




10/25/2019

New Safety Recall Advanced Communication – VB1



FCA US LLC (FCA US) has announced a safety recall on certain 2014 through 2019 Model Year (DS) RAM 1500 Pickup trucks equipped with a 3.0L Eco Diesel engine.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles may have been built with Exhaust Gas Recirculation (EGR) coolers that are susceptible to thermal fatigue. Thermal fatigue may cause the cooler to crack internally over time.  An EGR cooler with an internal crack will introduce preheated, vaporized coolant to the EGR system while the engine is running. In certain circumstances, this mixture interacts with other hydrocarbons and air in the system, potentially resulting in combustion within the intake manifold, which may lead to a vehicle fire.  A vehicle fire may increase the risk of injury to occupants and persons outside of the vehicle, as well as property damage.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to repair the vehicles.  The remedy for this condition is not currently available.  Dealers will be notified of the launch of this safety recall by way of established communication methods.



We ask that you please take the time to ensure that your personnel are aware of this communication and are prepared to execute a customer friendly process for inquiries regarding involved vehicles.



Customer Services Field Operations

FCA US LLC




FCA US LLC Chronology
2014-2019 Ram 1500 Eco Diesel Engine Compartment
Submitted on October 24, 2019



  • On May 22, 2019, the FCA US LLC (“FCA US”) Vehicle Safety and Regulatory Compliance (“VSRC”) organization opened an investigation into engine compartment fires in Ram 1500 3.0L Eco Diesel trucks.



  • Starting May 24, 2019, and continuing through June 2019, FCA US VSRC reviewed all Ram 1500 3.0L Eco Diesel fires reported to FCA US, and determined that a number of the fires originated in the general vicinity of the center of the engine compartment.



  • During the Month of July 2019, FCA US VSRC met with diesel engineers to understand potential causes and competent ignition sources within the area of origin.



  • From August to September 2019, FCA US VSRC held weekly meetings with diesel engineers to understand the circumstances in which fuel and oxygen interacted with a competent ignition source, reviewed details related to failure incidents, and examined returned parts from the field.



  • On September 10, 2019, FCA US VSRC inspected a 2017 Ram 1500 3.0L diesel to determine the origin and cause of a fire. The fire originated in the center of the engine, between the intake manifold and the fuel rail. A hole was found in the manifold.



  • Beginning on September 14, 2019, FCA US VSRC began reviewing warranty reports and repair orders for 3.0L diesel Ram 1500 vehicles related to Exhaust Gas Recirculation (“EGR”) coolers cracking or leaking.



  • On September 30, 2019, FCA US VSRC inspected a 2014 Ram 1500 3.0L diesel to determine the origin and cause of a fire. The fire originated in the center of the engine, between the intake manifold and the fuel rail. A hole was found in the manifold.



  • On October 2, 2019, FCA US VSRC received and began analyzing multiple reports of fires in 3.0L diesel Ram 1500 trucks from FCA Canada Inc. These reports allowed FCA US VSRC to better understand the fire dynamics involved and to rule out climate as a potential exacerbating factor.



  • As of October 11, 2019, total EGR cooler warranty replacements is 8,909 reports at 49 Cs/1000.
  • As of October 11, 2019, FCA US has identified approximately 1,289 CAIRs, and 61 field reports potentially related to EGR cooler failure.



  • As of October 11, 2019, FCA US is unaware of any accidents and 4 minor injuries potentially related to this issue.



  • On October 17, 2019, FCA US determined, through the Vehicle Regulations Committee, to conduct a voluntary safety recall of the affected vehicles.




6 Affected Products

Vehicle

MAKE MODEL YEAR
RAM 1500 2014-2019




24 Associated Documents

Recall 573 Report – AMENDMENT 6

RCLRPT-19V757-6689.PDF 214.297KB

RCLRPT-19V757-6689




Recall 573 Report AMENDMENT 4

RCLRPT-19V757-5941.PDF 214.151KB

RCLRPT-19V757-5941




ISSUED Owner Notification Letter(Part 577)

RCONL-19V757-7484.pdf 516.742KB

RCONL-19V757-7484




ISSUED Owner Notification Letter(Part 577)

RCONL-19V757-6556.pdf 518.648KB

RCONL-19V757-6556




Remedy Instructions and TSB

RCRIT-19V757-5258.pdf 3978.105KB

RCRIT-19V757-5258




Remedy Instructions and TSB

RCRIT-19V757-8953.pdf 3970.012KB

RCRIT-19V757-8953




Recall 573 Report-Amendment 3

RCLRPT-19V757-5868.PDF 213.957KB

RCLRPT-19V757-5868




Remedy Instructions and TSB

RCRIT-19V757-1761.pdf 3897.843KB

RCRIT-19V757-1761




Recall 573 Report – AMENDMENT 5

RCLRPT-19V757-2821.PDF 214.265KB

RCLRPT-19V757-2821




Recall 573 Report-Amendment 1

RCLRPT-19V757-3602.PDF 213.748KB

RCLRPT-19V757-3602




Recall 573 Report – Amendment 7

RCLRPT-19V757-7169.PDF 214.714KB

RCLRPT-19V757-7169




Recall 573 Report-Amendment 2

RCLRPT-19V757-3239.PDF 213.9KB

RCLRPT-19V757-3239




Manufacturer Notices(to Dealers,etc) – 11/01/2019 New Safety Recall Advanced Communication – VB1

RCMN-19V757-5848.pdf 100.491KB

RCMN-19V757-5848




ISSUED Interim Owner Notification Letter(Part 577)

RIONL-19V757-4940.pdf 56.472KB

RIONL-19V757-4940




Remedy Instructions and TSB

RCRIT-19V757-7152.pdf 3969.375KB

RCRIT-19V757-7152




Manufacturer Notices(to Dealers,etc)

RCMN-19V757-3839.pdf 174.812KB

RCMN-19V757-3839




Recall Quarterly Report #1, 2020-2

RCLQRT-19V757-5117.PDF 211.143KB

RCLQRT-19V757-5117




Manufacturer Notices(to Dealers,etc) – December 2019 SAFETY RECALL VB1: 2014-2019 DS 3.0L EGR Cooler Customer Handling

RCMN-19V757-0602.pdf 49.627KB

RCMN-19V757-0602




Manufacturer Notices(to Dealers,etc) – VB1 Owner Interim

RCMN-19V757-1387.pdf 56.472KB

RCMN-19V757-1387




Recall Acknowledgement

RCAK-19V757-4850.pdf 286.289KB

RCAK-19V757-4850




Chronology

RMISC-19V757-6098.pdf 123.595KB

RMISC-19V757-6098




Manufacturer Notices(to Dealers,etc) – 10/25/2019 New Safety Recall Advanced Communication – VB1

RCMN-19V757-9478.pdf 97.499KB

RCMN-19V757-9478




Defect Notice 573 Report

RCLRPT-19V757-7573.PDF 213.75KB

RCLRPT-19V757-7573




Recall Quarterly Report #2, 2020-3

RCLQRT-19V757-3700.PDF 211.248KB

RCLQRT-19V757-3700




Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=19V757&docType=RCL






Bestseller No. 1
Dorman 904-388 Exhaust Gas Recirculation (EGR) Cooler Compatible with Select Dodge/Ram Models
  • Direct replacement - this EGR cooler is made to match the fit and function of the original part on specific applications
  • Rigorously tested - heat transfer testing, burst testing and vehicle try-on testing ensures fit and reliability
  • Durable construction - this part is made from quality materials to ensure reliable performance and a long service life
  • Trustworthy quality - backed by a team of product experts in the United States and more than a century of automotive experience
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 2
EGR Cooler Gasket Compatible with Ram 3500 6.7L L6 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 PC-751927
  • 📦 Includes 1 (One) EGR Cooler Gasket
  • 👉 Fits list of vehicles in image gallery fitment chart
  • ✅ Exceptional Quality and Performance: This OE replacement egr cooler gasket is designed to meet, if not exceed, the performance and quality standards of the original equipment installed on your vehicle. Experience the same high-level performance as your original parts with this egr cooler gasket.
  • ✅ Direct Replacement, No Fuss: This OE replacement egr cooler gasket is meticulously designed for your specific vehicle
  • ✅ Perfect Compatibility: Compatibility is key. Make sure to check our product specifications (in image gallery) to confirm that this OE replacement egr cooler gasket matches your vehicle
Bestseller No. 3
Dorman 904-333 Exhaust Gas Recirculation Cooler Kit Compatible with Select Dodge / Ram Models (OE FIX)
  • Improved reliability - this replacement EGR cooler features a spiral tube design, reducing clogging experienced with the original manufacturer's design
  • Superior durability - precision-engineered using welded stainless steel for long service life
  • Rigorously tested - heat transfer testing, burst testing and vehicle try-on testing ensures fit and reliability
  • Hardware included - all necessary O-rings, gaskets, and application-specific hardware included
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 4
Dorman 903-003 Exhaust Gas Recirculation (EGR) Cooler Clamp Compatible with Select Dodge/Ram Models
  • Direct replacement - this exhaust gas recirculation (EGR) cooler clamp is designed to match the fit of the original clamp and is recommended for replacement during EGR cooler service
  • Ideal solution - engineered from stainless steel to withstand extreme heat and to resist corrosion
  • Durable construction - designed and manufactured to strict specifications for reliable performance
  • Trustworthy quality - backed by a team of product experts in the United States and more than a century of automotive experience
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 5
HPS Performance Polish Shortram Air Intake Kit + Heat Shield Cool Ram Compatible for 2008-2014 Mitsubishi Lancer 2.0L 2.4L Non Turbo with EGR Tube, 827-162P
  • Fits 2008-2014 Mitsubishi Lancer 2. 0L / 2. 4L Non-Turbo EGR Tube Equipped. No modification is required. CARB Exempt: No
  • Fine-tuned by HPS to deliver dyno proven performance gains +6. 9 Whp horsepower, +5. 2 Ft/lbs. torque and improve throttle response; Does NOT require tuning after the install
  • Polish light weight mandrel-bent aluminum alloy piping replaces the stock restrictive air box and optimize the air flow
  • Features HPS signature race proven reinforced silicone hoses and industrial grade 100% stainless steel T-bolt clamps. The included HPS Washable/Reusable Performance Air Filter is backed by Limited Lifetime
  • The included installation instruction has clear pictures and description to guide the installer throughout the whole process
Bestseller No. 6
Dorman 904-311 Exhaust Gas Recirculation Cooler Kit Compatible with Select Dodge Models (OE FIX)
  • Improved reliability - this replacement EGR cooler features a spiral tube design, reducing clogging experienced with the original manufacturer's design
  • Superior durability - precision-engineered using welded stainless steel for long service life
  • Rigorously tested - heat transfer testing, burst testing and vehicle try-on testing ensures fit and reliability
  • Hardware included - all necessary O-rings, gaskets, and application-specific hardware included
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 7
Upgraded EGR Cooler Kit&Gaskets for Ford for 04-07 F250 F350 F450 F550 Super Duty 04-10 E350 E450 Super Duty 04-05 E350 Club Wagon Excursion 04-07 F650 F750 6.0L Diesel Turbo 904-262
  • For 2004 2005 2006 2007 2008 2009 2010 Ford E350 Super Duty E450 Super Duty For 2004-2007 Ford F250 Super Duty F350 Super Duty F450 Super Duty F550 Super Duty F650 F750 For 2004-2005 Ford E350 Club Wagon Ford Excursion
  • Features: Will not fits 2003 EGR cooler round style 1For 6.0L 363Cu. In. V8 DIESEL OHV Turbocharged
  • Replacement OEM Number: 904-262, 4C3Z-9P456-AH, 4C3Z9P456AH, 4C3Z9P456AF, 4C3Z-9P456-AJ, 904-262, 4C3Z-9P456-AF, 4C3Z9P456AA, 4C3Z9P456AC, 4C3Z-9P456-AA, 4C3Z-9P456-AC
  • Aftermarket Product with Premium Quality. Support One Year Warranty.
Bestseller No. 8
FEL-PRO ES 73066 EGR/Exhaust Air Supply Gasket
  • Meets or exceeds all original equipment specifications
  • Application specific design to ensure a perfect fit
  • Unsurpassed quality you can trust
  • Validated for fit, form and function
  • Each Fell-Pro gasket, no matter how small, is engineered to exacting standards with proprietary design, engineering and manufacturing processes
Bestseller No. 9
Dorman 904-405 Exhaust Gas Recirculation Cooler Kit - Not CARB Compliant Compatible with Select Ford Models (OE FIX0
  • Improved reliability - this replacement EGR cooler features a spiral tube design, reducing clogging experienced with the original manufacturer's design
  • Superior durability - precision-engineered using welded stainless steel for long service life
  • Rigorously tested - heat transfer testing, burst testing and vehicle try-on testing ensures fit and reliability
  • Hardware included - all necessary O-rings, gaskets, and application-specific hardware included
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 10
FEL-PRO 73014 EGR/Exhaust Air Supply Gasket
  • Meets or exceeds all original equipment specifications
  • Application specific design to ensure a perfect fit
  • Engineered for the sealing repair environment
  • Validated for fit, form and function
  • Unsurpassed quality you can trust

Last update on 2024-01-28 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.

Leave a Comment

Share to...
