Safety Recall Y36 – Wheel Studs – 2012-2021 RAM 3500/4500/5500

“This site contains affiliate links for which OEMDTC may be compensated”

May 27, 2021 NHTSA CAMPAIGN NUMBER: 21V398000

Wheel Studs May Break

Wheel separation can cause a vehicle crash.



NHTSA Campaign Number: 21V398

Manufacturer Chrysler (FCA US, LLC)

Components WHEELS

Potential Number of Units Affected 447,985



Summary

Chrysler (FCA US, LLC) is recalling certain 2012-2021 RAM 3500, 3500 Cab Chassis, 4500 Cab Chassis, and 5500 Cab Chassis vehicles. Incorrect information in the Service and Owner’s Manuals may cause the flanged lug nuts to be over-tightened, which could result in a broken wheel stud and possible wheel separation.



Remedy

Dealers will update the torque specification in the owner’s manual and other published service documents. Dealers will also inspect the vehicle’s wheel studs, replacing them if necessary, free of charge. Owner notification letters were mailed on November 30, 2021. Campaign Y36 owner notification letters were mailed on November 30, 2021. Campaign Y26 owner notification letters were mailed on December 1, 2021. Owners may contact FCA US customer service at 1-800-853-1403. FCA US’s numbers for this recall are Y26 and Y36.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.



Check if your Vehicle has a Recall




Safety Recall Advanced Communication – Y26

FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2) Ram 3500 Pickup, (DD) Ram 3500 Cab Chassis, (DP) Ram 4500/5500 Cab Chassis trucks.

VINs identified as being involved in this campaign are currently live and searchable. Stop sale is in effect for the above-identified vehicles.

Vehicles impacted by a stop sale are eligible for reimbursement allowance through the Recall Floorplan Reimbursement Policy (RFPRP), which can be requested upon recall claim submission.



IMPORTANT: Some of the involved vehicles may be in dealer new vehicle inventory. Federal law requires you to complete this recall service on these vehicles before retail delivery. Violation of this requirement by a dealer could result in a civil penalty of up to $21,000 per vehicle. Involved vehicles can be determined by using the VIP inquiry process.



REASON FOR THIS SAFETY RECALL

Some of the above vehicles with flanged lug nuts may have their lug nuts over-torqued during service due to an incorrect torque specification in the Service & Owner’s manuals. A yielded wheel stud may eventually break, which could lead to a wheel separating from the vehicle during operation. A wheel separating from the vehicle could cause a vehicle crash without prior warning and/or the wheel/tire could pose a risk to other vehicles or pedestrians.



SERVICE ACTION

FCA US will conduct a voluntary safety recall to inspect the wheel studs and update the torque specification in owner’s information and published service documents. Vehicles found with studs that are potentially yielded will have a new stud installed and the lug nuts tightened to the updated torque specification. Dealers will be notified of the launch of this safety recall by way of established communication methods. This recall is estimated to launch in the 3rd Quarter of 2021.




Revision 2 December 2021

Dealer Service Instructions for:

Safety Recall Y36 / NHTSA 21V-398 Wheel Studs



NOTE: Updated repair to commonize with Y26 campaign. The procedure and LOPs should be considered all NEW.



Remedy Available

2012 – 2021 (D2) Ram 3500 Pickup
(DD) Ram 3500 Cab Chassis
(DP) Ram 4500/5500 Cab Chassis



NOTE:  Some vehicles above may have been identified as not involved in this recall and therefore have been excluded from this recall.



IMPORTANT:  Some of the involved vehicles may be in dealer used vehicle inventory.  Dealers should complete this recall service on these vehicles before retail delivery.  Dealers should also perform this recall on vehicles in for service.

Involved vehicles can be determined by using the VIP inquiry process.



Subject

The flanged wheel lug nuts on about 11,000 of the above vehicles may have been over-torqued during service to an incorrect torque specification in the Service & Owner’s manuals. A yielded wheel stud may eventually break, which could lead to a wheel separating from the vehicle during operation. A wheel separating from the vehicle could cause a vehicle crash without prior warning and/or the wheel/tire could pose a risk to other vehicles or pedestrians.



Repair

The Y36 campaign launched in June, 2021 for vehicles without a history of service, upfit, etc.  The previous repair required dealers to review their own records, in addition to the vehicle’s, and confirm no service, upfitting, or any modifications were performed which required the removal of the wheels and tire assemblies.  If no service, upfitting, or modifications were performed, an addendum card and label were to be attached to the vehicle and the campaign need for the prior Interim LOP.  Any vehicle with the previous Interim  LOP (22closed.



At this time, the repair has now been updated to match the Y26 campaign repair to include a vehicle inspection.  Parts are now available, eliminating the Y3-6L-81) claimed, must now be inspected and repaired, if necessary.



PROCESS:

  1. Remove all four wheel and tire assemblies and inspect all wheel studs – reference section Wheel Stud Inspection Procedure.
    1. One (1) “Mopar Essential Tool #2077700030 – Go/No-Go Gauge” was shipped to every dealer the week of November 1, 2021. Please ensure the gauge is kept in a secure location to be utilized for the duration of this campaign.
    2. If there are any questions regarding delivery of the “Mopar Essential Tool #2077700030 – Go/No-Go Gauge”, contact the Mopar Essential Tool Call Center ( 1-855-298-2687 / moparessentialtools.com ).
    3. Additional tools are available in limited quantities, if required. Utilize the above Mopar Essential Tool Call Center or website to submit a request.



  1. If any of the wheel studs do not pass inspection – reference sections B. Front Axle Stud Removal and Installation Procedure or section C. Rear Axle Stud Removal and Installation Procedure.  If all studs pass inspection, proceed to item #3.



  1. Dealers are required to locate the lug nut torque specification page in the owner’s manual/user’s manual and attach a label over the existing lug nut torque specifications information page. Also insert and staple the addendum card to the same page – reference section D. Owner’s Manual Update.
    1. Process Steps to obtain Addendum Card(s) and/or Adhesive Label(s):
      1. Access the “DealerCONNECT” website.
      2. Select the “Marketing” link in the header of DealerCONNECT.
      3. Locate the “Product Information” section heading on the Marketing page.
      4. Select the “Literature and Merchandising Materials” link in the product information section.
      5. Locate the “Mopar” section heading on the Literature and Merchandising Materials page.
      6. Select the “Recall Labels /Cards” link listed in the MOPAR section.
      7. Select Item>Update Cart>Submit Order. cards) at a time and a maximum of 50 pieces. Note that labels and
  1. Reference: Y26 or Y36 Addendum and Label/Sticker – they are the same.
  2. Dealers can order a minimum of 10 pieces (both labels and addendum addendum cards should be ordered in sets.



Parts Information

Due to the significant quantity of vehicles and parts involved in this campaign, a STAR Case must be submitted in order to request parts.



Please access Cherwell via the Service Library link to create a STAR Case.



Please provide the VIN, Model Year and Family, Mileage, Dealer Code and failed stud location(s) and quantities (i.e. Driver Front – 2, Passenger Rear – 4).  Review the parts lists below and provide required parts list in STAR Case.



Important – When submitting a STAR Case-On the Repair Information Screen when selecting the “Next Step” – be sure to select “Y26 Wheel Stud Recall” from the list of options. This will route your ticket to the appropriate agent. DO NOT select “I will wait for STAR Response, or any other available option.



NOTE:  Parts are packaged in kits.  Most kits contain material to repair one or more wheels depending on the number of failed studs per truck.  It is expected that

the unused parts are maintained for future vehicles requiring repair. PLEASE CHECK YOUR DEALER INVENTORY PRIOR TO PROVIDING REQUIRED PARTS LIST TO STAR.



STAR will then verify that all of the required information is accurate, and will place the order for the appropriate parts.



Dealers must place their own axle fluid orders, if fluid is needed.



# MY Vehicle Axle Sales Code Required Part Description C-Kit P/N Qty per C-Kit Qty.
1 20122021 D2 DD DP Failed Inspection M14x1.50×70.00 Wheel Stud – Front CSZMY261AA 10 ONLY quantity failing inspection is needed; note: DP – 10 per wheel, Others – 8 per wheel; x 2 rear wheels
2 20122021 DP DRY Failed Inspection M14x1.50×88.00 Wheel stud – Rear CSZMY262AA 8 ONLY quantity failing inspection is needed; note:

DP – 10 per wheel x 2 rear wheels

3 20122021 D2 DD Failed Inspection M14x1.50×80.00 Wheel Stud – Rear CSZMY263AA 5 ONLY quantity failing inspection is needed; note:

8 per wheel x 2 rear wheels

4 20122021 D2 DD DP ONLY if needed Flanged Lug Nut CSZMY264AA 8 ONLY if needed; note: DP – 10 per wheel, Others –

8 per wheel; x 4 front/rear wheels

5A 20122021 D2 DD DRX Required for Rear Stud Replacement BOLT, Rear Hub – Hex Flange Head, 7/16-14×35.00 CSZMY266AA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
5B 20192021 DD DRC Required for Rear Stud Replacement BOLT, Rear Hub – Hex Flange Head, 7/16-14×35.00 CSZMY266AA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
5C 20122018 D2 DRS Required w/ Rear Stud Replacement BOLT, Rear Hub – Hex Flange Head, 7/16-14×35.00 CSZMY266AA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
6A 20192020 D2 DRC Required for Rear Stud Replacement Bolt, M12 Rear hub CSZMY267AA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
6B 2021 D2 DRC Required for Rear Stud Replacement BOLT, M12 Rear Hub CSZMY267AA 8 required when any REAR studs fail inspection; note: 12 per wheel; x2 rear wheels
6C 20192021 DP DRY Required for Rear Stud Replacement BOLT, M12 Rear Hub CSZMY267AA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
7 20122018 DP DRT Required w/ Rear Stud Replacement BOLT, M12 Rear Hub CSZMY26JAA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
8 20122018 D2 DD DRX / DRS Required w/ Rear Stud Replacement Seal, Wheel Bearing CSZMY269AA 5 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
9A 20192021 D2 DD DRX Required for Rear Stud Replacement Seal, Wheel Bearing CSZMY26BAA 2 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
9B 20192021 DD DRC Required for Rear Stud Replacement Seal, Wheel Bearing CSZMY26BAA 2 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
10 20122018 DP DRT Required w/ Rear Stud Replacement Seal, Wheel Bearing CSZMY26KAA 4 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
11A 20192021 D2 DRC Required for Rear Stud Replacement Seal, Wheel Bearing CSZMY26DAA 5 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
11B 20192021 DP DRY Required for Rear Stud Replacement Seal, Wheel Bearing CSZMY26DAA 5 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
12A 20192021 D2 DD DRX Required for Rear Stud Replacement O-Ring, Axle Shaft CSZMY26CAA 10 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
12B 20192021 DD DRC Required for Rear Stud Replacement O-Ring, Axle Shaft CSZMY26CAA 10 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
13 20192021 D2 DRC Required for Rear Stud Replacement O-Ring, Axle Shaft CSZMY26EAA 10 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
14 20122018 D2 DD DRX / DRS Required w/ Rear Stud Replacement O-Ring, Axle Shaft CSZMY26AAA 8 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
15 20122018 DP DRT Required w/ Rear Stud Replacement O-Ring, Axle Shaft CSZMY268AA 4 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
16 20192021 DP DRY Required for Rear Stud Replacement O-Ring, Axle Shaft CSZMY26FAA 10 required when any REAR studs fail inspection; note: 1 per wheel; x2 rear wheels
17 20122021 DP Required for Rear Stud Replacement Bolt, Rear Rotor to hub CSZMY26GA A 10 required when any REAR studs fail inspection; note: 10 per wheel; x2 rear wheels
18 20122021 D2 DD Required for Rear Stud Replacement Bolt, Rear Rotor to hub CSZMY26HAA 8 required when any REAR studs fail inspection; note: 8 per wheel; x2 rear wheels
19 20122021 DP Required for Rear Stud Replacement Bolt, Tone Ring CSZMY265AA 5 required when any REAR studs fail inspection; note: 5 per wheel; x2 rear wheels



Axle Fluid Part Numbers

MY Vehicle Sales Code Axle Fluid PN
2012-2018 D2,DD, DX DRX 68210057AB
2012-2018 D2 DRS
2012-2018 DP DRT 68218655AA MS-9763
2019-2021 DP DRY 68449546AA MS-A0759
2019-2021 D2,DD DRX
2019-2021 D2 DRC 68449547AA MS-8985



Parts Return

Parts returns are not required for this campaign.



Special Tools

The following special tools are required to perform this repair:

➢ 8677 Remover, Ball Joint
➢ 2067700030 Guide, Hub
➢ 8954A Socket, Hub Nut 6 Pin
➢ 2029500030 Socket, Hub Nut 9 Pin
➢ 2066600030 Socket, Hub Nut 12 Pin
➢ 2066700030 Installer, Hub Seal  (12.0” Ring Gear)
➢ 8693 Installer, Hub Seal  (11.5” Ring Gear)
➢ C-4171 Handle
➢ 2077700030 Stud Inspection Tool



Service Procedure

A. Wheel Stud Inspection Procedure



  1. Remove the front and rear wheel and tire assemblies.



  1. Using a wire brush clean the threads on all of the wheel studs.



  1. Measure approximately 25mm from the axle flange surface up the stud and place a mark (Figure 3). If no measurement tool is available, use the color of the stud to identify the measurement area (Figure 2).



  1. Attempt to insert the stud measurement tool in the following locations of the stud at different angles: (Figure 2). a) At the base of the wheel stud.

a) At the base of the wheel stud.

b) At the center of the 25mm measurement area.

c) Near the 25mm mark.



  1. Did the measurement tool insert fully into ANY of the wheel studs at all three locations? See sample illustrations below (Figure 3 and Figure 4).



  • If YES (aka. any Bad Studs), continue to section B. Front Axle Stud Removal and Installation Procedure or section C. Rear Axle Stud Removal and Installation, depending on failed stud wheel location.



  • If NO (aka. All Good Studs), reinstall the wheel and tire assemblies by tightening all of the lug nuts to 175N·m (129ft. lbs.) and continue to section D. Owner’s Manual Update.



B.  Front Axle Stud Removal and Installation Procedure



  1. Raise and support the vehicle.



  1. Remove the front tires and wheel assemblies.



  1. Attach special tool 8677 onto the front hub and press the wheel stud out of the wheel hub (Figure 5).



  1. Install the NEW wheel stud into the flange.



  1. Install three proper sized washers onto the stud, then install a lug nut with the flat side of the nut against the washer.



  1. Tighten the lug nut until the stud is pulled into the hub flange. Verify that the stud is properly seated into the flange and no gap is present (Figure 6).



NOTE: Do not use an air impact tool to install the stud.



NOTE: Do Not Exceed 175 N·m (129ft. lbs.) of torque on the lug nut.



  1. Remove the lug nut and washers.



  1. Install the wheel and tire assemblies.



  1. Tighten the lug nuts to 175 N·m (129ft. lbs.).



NOTE: Lug Nut torque specification is a NEW revised specification.



  1. Lower the vehicle.



  1. If required, proceed to section C. Rear Axle Stud Removal and Installation Procedure.



  1. If rear studs do not require replacement, proceed to section D. Owner’s Manual Update.



C.  Rear Axle Stud Removal and Installation Procedure

  1. Raise and support the vehicle.



  1. Remove the rear tire and wheel assemblies.



  1. Remove the     brake caliper adaptor bolts and brake caliper as an assembly and support the caliper (Figure 8).



  1. Remove the axle flange bolts (Figure 9).



  1. Slide the axle shaft out of the axle tube.



  1. Remove the retaining clip from the hub. Note the direction it is installed (Figure 10).



  1. Remove the hub nut key (Figure 11).

NOTE: If hub nut key will not remove freely, loosen or tighten hub nut to free the key.



  1. Using Socket, Hub Nut 6 Pin 8954A, or Socket, Hub Nut 9 Pin 2029500030, or Socket, Hub Nut 12 Pin 2066600030 remove the hub nut (Figure 12).



  1. Remove the hub assembly from the vehicle and set on a clean surface.



  1. If equipped: Remove the tone ring bolts.



  1. If equipped: Remove the tone ring.



  1. Place a mark on the hub and rotor for re-assembly.



  1. Remove the rotor bolts (Figure 13).



  1. Separate the brake rotor from the wheel hub.



  1. Attach special 8677 tool to hub and extract the wheel stud(s) (Figure 14).



  1. Install the NEW stud into the flange, install three proper sized washers onto the NEW stud, then install a lug nut.



  1. Tighten the lug nut until the stud is pulled into the hub flange. Verify that the stud is properly seated into the flange and no gap is present.



NOTE: Do not use an air impact tool to install the stud.



NOTE: Do Not Exceed 175 N·m (129ft. lbs.) of torque on the lug nut.



  1. Remove the lug nut and washers.



  1. Pry out the hub bearing seal from the back of the hub.



  1. Wipe the inner hub clean and repack the inner and out bearings with grease.



  1. Install the rear hub bearing.



  1. Install NEW grease seal with Installer, Hub Seal 2066700030 and Handle C4171 for 0” Ring Gear or Installer, Hub Seal 8693 for 11.5” Ring Gear (Sales Code DRC = 12.0”) (Sales Code DRX=11.5”) (Figure 15).



  1. Align the hub and rotor marks previously marked, and position the brake rotor to the wheel hub.



  1. Install the NEW rotor to hub bolts and tighten to 155N·m (144ft. lbs.).



  1. If equipped: Position the tone ring to the rotor.



  1. If equipped: Install the tone ring bolts and tighten to 26 N·m (17ft. lbs.).



  1. Install the Guide, Hub 2012800031 hub guide onto the axle tube and slide the hub over the guide and onto the axle tube and install front bearing into the hub (Figure 16).



  1. Install the hub bearing nut



2029500030 and tighten the hub bearing nut to 95 N·m (70 ft. lbs.) then reverse the nut 30° and align to the nearest notch (Figure 11).



  1. Install the hub nut locking key (Figure 11).



  1. Install the retainer ring (Figure 10).



NOTE: Retaining ring follows threads, with the hook side on the closest  thread to the key.



  1. Clean the axle flange and hub.



  1. Install a NEW Axle Shaft O-ring or gasket (Figure 17).



  1. Slide axle shaft into the axle tube.



  1. Install NEW axle shaft flange bolts and tighten the bolts to your specific vehicle family, model, year and sales code, and bolt part number, see chart below (Figure 18).



  1. Position the caliper adapter and caliper to the mounting bracket (Figure 8).



  1. Install the two rear caliper adapter bolts and tighten to:

2012 – 2018 D2, DD 300N·m (221ft. lbs.) (Figure 8).

2019 – 2021 D2, DD 353N·m (260ft. lbs.) (Figure 8).

2012 – 2021 DP 545N·m (402ft. lbs.) (Figure 8).



  1. Remove the rear differential oil fill plug (Figure 19).



  1. Verify the oil level is within 0.25” of the fill plug, add as needed (Figure 19).



  1. Install the fill plug and tighten to 32N·m (24ft. lbs.)



  1. Install the tire and wheel assemblies.



  1. Tighten the lug nuts to 175 N·m (129ft. lbs.).



NOTE: Lug Nut torque specification is a NEW revised specification.



  1. Lower the vehicle and proceed to Section D. Owner’s Manual Update.



D. Owner’s Manual Update



  1. Obtain the owner’s/user’s manual from the vehicle’s glove box, and attach the adhesive label over the existing wheel lug nut torque specifications section. Staple the addendum card onto the same page of the manual and reinstall owner’s/user’s manual into the glove box (Figure 20).



NOTE: If the owner’s manual is not available, provide the addendum/label to the customer and advise them to attach the label and the addendum card in the lug nuts torque section of the manual.



INFORMATION LOCATION MAY VARY FROM VEHICLE FAMILY AND MODEL YEAR.  Please ensure the label is placed over the existing incorrect torque information.  The following two examples are variances in location of the lug nut torque specification:







30 Affected Products

Vehicles

MAKE MODEL YEAR
RAM 3500 2012-2021
RAM 4500 2012-2021
RAM 5500 2012-2021




31 Associated Documents

Recall Quarterly Report #1, 2021-2

RCLQRT-21V398-3281.PDF 211.14KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.19 KB]




Remedy Instructions and TSB

RCRIT-21V398-7395.pdf 519.752KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [507.57 KB]




Manufacturer Notices(to Dealers,etc) NSRAC re REVISED Safety Recall Advanced Communication Y26

RCMN-21V398-1077.pdf 348.158KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [340.00 KB]




Manufacturer Notices(to Dealers,etc) – Media Release re FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2) Ram 3500 Pickup, (DD) Ram 3500 Cab Chassis, (DP) Ram 4500/5500 Cab Chassis trucks

RCMN-21V398-4470.pdf 98.548KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [96.24 KB]




Manufacturer Notices(to Dealers,etc) – Media Release re FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2) Ram 3500 Pickup, (DD) Ram 3500 Cab Chassis, (DP) Ram 4500/5500 Cab Chassis trucks

RCMN-21V398-9365.pdf 98.284KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [95.98 KB]




Manufacturer Notices(to Dealers,etc) – Media release re FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2) Ram 3500 Pickup, (DD) Ram 3500 Cab Chassis, (DP) Ram 4500/5500 Cab Chassis trucks

RCMN-21V398-7480.pdf 295.656KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [288.73 KB]




Recall Acknowledgement

RCAK-21V398-4715.pdf 645.515KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [630.39 KB]




Defect Notice 573 Report

RCLRPT-21V398-4676.PDF 216.785KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [211.70 KB]




Manufacturer Notices(to Dealers,etc)

RCMN-21V398-9812.pdf 100.74KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [98.38 KB]




Manufacturer Notices(to Dealers,etc) – Dealer Letter for Mailed Material re FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2/DD/DP) RAM 3500-5500 vehicles. Reference campaign #Y36.

RCMN-21V398-2086.pdf 244.365KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [238.64 KB]




Remedy Instructions and TSB

RCRIT-21V398-3463.pdf 519.421KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [507.25 KB]




Recall Quarterly Report #2, 2021-3

RCLQRT-21V398-4771.PDF 211.242KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.29 KB]




Recall Quarterly Report #3, 2021-4

RCLQRT-21V398-0732.PDF 211.348KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [206.39 KB]




Interim Owner Notification Letter(Part 577)

RIONL-21V398-5131.pdf 55.949KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [54.64 KB]




ISSUED Owner Notification Letter(Part 577)

RCONL-21V398-5349.pdf 56.937KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [55.60 KB]




ISSUED Owner Notification Letter(Part 577)

RCONL-21V398-8099.pdf 519.917KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [507.73 KB]




Manufacturer Notices(to Dealers,etc) – Dealer Notice re Safety Recall Y26 Dealer Service Instructions for MY 2019- 2021 tentative release Nov. 23, 2021, Measurement gauge being shipped to dealers the week on Nov. 1st.

RCMN-21V398-9771.pdf 166.925KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [163.01 KB]




Remedy Instructions and TSB

RCRIT-21V398-4404.pdf 2610.567KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.49 MB]




Remedy Instructions and TSB

RCRIT-21V398-2114.pdf 3107.095KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.96 MB]




ISSUED Owner Notification Letter(Part 577)

RCONL-21V398-4582.pdf 177.4KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [173.24 KB]




Remedy Instructions and TSB

RCRIT-21V398-9602.pdf 2228.978KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.13 MB]




Remedy Instructions and TSB

RCRIT-21V398-4374.pdf 3119.316KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.97 MB]




Remedy Instructions and TSB

RCRIT-21V398-7447.pdf 2010KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.92 MB]




ISSUED Owner Notification Letter(Part 577)

RCONL-21V398-1717.pdf 415.749KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [406.00 KB]




Manufacturer Notices(to Dealers,etc) – NSRAC re REVISED Safety Recall Advanced Communication Y26 FCA US LLC (FCA US) has announced a safety recall on certain 2012 through 2021 Model Year (D2) Ram 3500 Pickup, (DD) Ram 3500 Cab Chassis, (DP) Ram 4500/5500 Cab Chassis trucks.

RCMN-21V398-3979.pdf 294.778KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [287.87 KB]




Recall 573 Report

RCLRPT-21V398-2156.PDF 217.561KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [212.46 KB]




Manufacturer Notices(to Dealers,etc) – ADDITIONAL UPDATE – SAFETY RECALL Y26 – WHEEL STUDS

RCMN-21V398-9028.pdf 178.63KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [174.44 KB]




Remedy Instructions and TSB

RCRIT-21V398-6652.pdf 3083.984KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.94 MB]




Remedy Instructions and TSB

RCRIT-21V398-4950.pdf 1263.066KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [1.20 MB]




Remedy Instructions and TSB

RCRIT-21V398-5852.pdf 2701.358KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.58 MB]




Remedy Instructions and TSB

RCRIT-21V398-3540.pdf 2699.463KB

Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download [2.57 MB]


Latest Recalls Documents

For the Latest and Most Recent Recalls Information Visit the link below…

https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=21V398&docType=RCL






Bestseller No. 1
5PCS Wheel Studs,49mm Long & M12x1.5 Steel Lug Bolts,OEM#610-266 90942-02049 Wheel Lug Stud Car Accessories Compatible with Chevrolet Lexus Toyota Scion Pontiac
  • [Compatible Models]-These wheel studs are compatible with Geo Pontiac Lexus Scion Toyota Chevrolet Models. Refer to the description page for specific models. Please check the oem model carefully to make sure our steel wheel stud is what you need before placing order, thanks!
  • [Customer Guide]-Replacement for: 610-266,610-266.1, 610-266.40,98485.1, 9094202049, 90942-02049, 90942-02017, 90942-02037, 9094202067, 90942-02070, 90942-02082, 94851865. Conforms to OE specifications in terms of size, surface and function so that be assured to purchase and use,please.
  • [Wheel Stud Information]-Package included: 5 pcs steel wheel studs. These wheel bolts have a thread size of M12x1.5, a thread length of 49mm and a thread diameter 12mm. Recommend you to use a professional stud installation tool to install the wheel studs to protect your hands.
  • [Powerful Function]-The purpose of wheel studs is to hold the wheels tightly to the car and our screws are made of strong and durable steel, not easy to be deformed and damaged. You don't have to worry about any safety issues on the road as long as the wheel hub bolts are used correctly.
  • [Perfect Service]-Assure you that our bolts are manufactured under strict quality control. Your satisfaction and shopping experience are our primary focus! If you have any questions about our bolts, please do not hesitate to contact us! Happy to be of service to you.
Bestseller No. 2
22800 Wheel Stud Installer,Wheel Stud Installer Tool,Safe, Saves Time, Effort,Tire Stud Tool,Wheel Stud Installer Replace,Compatible with Most All Automotive Wheels and Light-Duty Truck Wheel Stud
  • [High Quality Material] Our wheel stud installer is made of high quality carbon steel and its surface is oxidized and rust-proof. Strong and wear-resistant, long service life.
  • [Applicable] 22800 wheel stud installation tool is compatible with almost all vehicle wheels and light truck wheel studs, and is applicable to most car SUV RV light truck wheel studs.
  • [Features] It is easy to install new wheel studs, and use a ratchet or impact wrench to firmly pull the new studs in place.
  • [Easy to Use] First, pull the new stud firmly into place. Next, place the tool on the stud shaft. Finally, tighten the lug nut tool to pull the stud in place. Vehicle studs are often too long, this tool will help.
  • [Easy to Use] First, pull the new stud firmly into place. Next, place the tool on the stud shaft. Finally, tighten the lug nut tool to pull the stud in place. Vehicle studs are often too long, this tool will help.
SaleBestseller No. 3
10PCS M12x1.5 Car Wheel Studs,Steel Tire Studs Replacemnet OEM#9094202067,90942-02037,Compatible with Toyota Chevrolet Lexus,Essential Car Accessories Lug Bolts Secure Wheel Hubs (10PCS)
  • ➤ Replacement Wheel Studs: Automotive wheel lug bolts are an important component that connects the wheel to the vehicle's hub and can be used to replace worn or damaged original wheel studs. They are replacements OEM#610-266, 610-266.1, 9094202049, 90942-02049, 90942-02017, 90942-02037, 9094202067, 90942-02070, 90942-02082 to ensure wheels are securely fastened.
  • ➤ Tire Studs Compatibility: These studs for tires are compatible with Scion, Lexus, Toyota, Geo Prizm, Pontiac Vibe, Chevrolet Prizm. For specific models, please refer to the product description. Before purchasing, confirm that your vehicle model and wheel specifications match the selected studs to ensure accuracy and reliability during installation.
  • ➤ Selected Steel Materials: We have selected premium quality steel for our M12x1.5 lug studs to ensure strength and wear resistance. With good tensile strength and durability, the steel material can withstand high loads, vibrations and extreme environmental conditions, and will not be easily deformed or damaged, making them your must-have car accessories.
  • ➤ Secure Vehicle Wheel Hub: This automotive lug bolts is effective in securing the wheel of a car. After installation, the wheel bolts connect the tire to the wheel hub tightly, prevent extra friction and loosening, provide stable driving performance and minimize the friction between the wheel hubs and the car lug stud for your driving safety.
  • ➤ Some Friendly Reminder: Our wheel stud have 12mm diameter and 1.5mm pitch. Please check the specifications carefully. We recommend replacing the appropriate number of studs at the same time for added security. Regularly check the tightness of the studs and make sure they are not loose or damaged. If you have any questions, don't hesitate to contact us at any time!
Bestseller No. 4
A-Premium M12-1.50 Wheel Studs Compatible with Chevrolet Equinox Malibu Impala Monte Carlo S10 GMC Envoy Cadillac Buick Front or Rear Side 10-PC Set
  • 【Vehicle Fitment】 Compatible with Buick Regal 1987/1995-1996/1998-2004, Century 1989/1993/1995-2005, LeSabre 1992/1994-2005, Park Avenue 1993/1997-2005, Riviera 1997, Rendezvous 2002-2007, Terraza 2005, Allure/LaCrosse 2005-2009, Rainier 2006-2007, Lucerne 2006-2011; Compatible with Cadillac DeVille 1989-1996/2000-2005, Fleetwood-RWD 1993-1994, Fleetwood-RWD 1996, Seville 1997/1999-2003, DeVille 1997-1999, Eldorado 1998-2001, CTS 2003-2007, SRX 2004-2009, STS 2005-2009/2011, DTS 2006-2010
  • 【Vehicle Fitment】 Compatible with Chevrolet Blazer 1995-2002, Camaro 1984/1986/1988/1992/1994-2002, S10 1984-1985/1987-1989/1991-2002, Corvette 1984-1996/1998-2004/2008, Monte 1987/2000-2007, Caprice 1991/1994-1996, Impala 1995-1996/2000-2013, Malibu 1997-2012, Venture 1998-2005, Lumina 2001, S10 2003-2004, Blazer 2003-2005, Classic 2004-2005, Colorado 2004-2012, Equinox 2005-2006, Uplander 2005-2008, Trailblazer EXT 2006, Trailblazer 2006-2009, HHR 2006-2011, Corvette 2010-2012
  • 【Vehicle Fitment】 Compatible with GMC Canyon 2004-2012, Jimmy 2005, Envoy XL 2006, Jimmy 1994-2001, Sonoma 1994-2002, Envoy 2006-2009; Compatible with Hummer H3 2006-2009; Compatible with Isuzu Hombre 2000-2000; Compatible with Oldsmobile Cutlass 1985/1999, 88 1997-1999, Bravada 1999-2001; Compatible with Pontiac Trans Sport 1991/1997, Firebird 1998-2000/2002, Grand Prix 1997-2008, Trans Sport 1999, Grand Am 1999-2005, Montana 1999-2005/2008, Sunfire 2003-2005; Compatible with Saab 9-7x 2008
  • 【Specifications】 Length: 33.655 mm; Thread Size: M12-1.5
  • 【Part Number】610-254, 610254, 9595178, 9590475, 12413071, BK0010231, 25693148, 18097800
Bestseller No. 5
Wheel Studs Kit,M12x1.5 Steel Lug Bolts (Long=49mm),Car Accessories Wheel Lug Stud OEM#610-266,90942-02049,Compatible with Chevrolet Lexus Toyota Scion Pontiac (10PCS)
  • 🩹 Replacement Wheel Studs: Automotive wheel lug bolts are an important component that connects the wheel to the vehicle's hub and can be used to replace worn or damaged original wheel studs. They are replacements OEM#610-266, 610-266.1, 9094202049, 90942-02049, 90942-02017, 90942-02037, 9094202067, 90942-02070, 90942-02082 to ensure wheels are securely fastened.
  • 🩹 Tire Studs Compatibility: These studs for tires are compatible with Scion, Lexus, Toyota, Geo Prizm, Pontiac Vibe, Chevrolet Prizm. For specific models, please refer to the product description. Before purchasing, confirm that your vehicle model and wheel specifications match the selected studs to ensure accuracy and reliability during installation.
  • 🩹 Selected Steel Materials: We have selected premium quality steel for our M12x1.5 lug studs to ensure strength and wear resistance. With good tensile strength and durability, the steel material can withstand high loads, vibrations and extreme environmental conditions, and will not be easily deformed or damaged, making them your must-have car accessories.
  • 🩹 Secure Vehicle Wheel Hub: This automotive lug bolts are effective in securing the wheel of a car. After installation, the wheel bolts connect the tire to the wheel hub tightly, prevent extra friction and loosening, provide stable driving performance and minimize the friction between the wheel hubs and the car lug stud for your driving safety.
  • 🩹 Some Friendly Reminder: Our wheel stud have 12mm diameter and 1.5mm pitch. Please check the specifications carefully. We recommend replacing the appropriate number of studs at the same time for added security. Regularly check the tightness of the studs and make sure they are not loose or damaged. If you have any questions, don't hesitate to contact us at any time!
Bestseller No. 6
JAVIK Front/Middle Wheel Studs 7515513 for Polaris Sportsman Ranger Outlaw Magnum Trail Blazer Trail Boss Predator Scrambler ATP Hawkeye 8PCS
  • 【Fitment】This Wheel Studs fit for various of models. Please check "Product Description". Beside you could use "Amz Confirmed Fit" garage tool to know it fit or not faster (Select vehicle / year / make / model).
  • 【Feature & Material】 Class 12.9 wheel studs, the highest grade of bolts produced. Made by SCM435 alloy steel, the intensity is 1220Mpa and the hardness is 39-44HRC.
  • 【OEM#】Front/Middle 7515513 7542459 7547237.
  • 【Repalcement OEM#】7547211.
  • 【Package】Wheel Stud x 8; Nut x 8.
SaleBestseller No. 7
Dorman 610-566 M12-1.25 Serrated Wheel Stud - 14.38mm Knurl, 43.5mm Length Compatible with Select Scion / Subaru / Toyota Models, 10 Pack, GOLD
  • Durable material - carbon steel meets SAE automotive industry standards for strength and hardness
  • Corrosion tested - 72-hour salt spray testing simulates three years of corrosion resistance
  • Tensile tested - lug studs undergo industry-standard proof-load testing to ensure strength
  • Trustworthy quality - backed by team of professional engineers and quality control specialists in the United States
  • Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
Bestseller No. 8
A-Premium 10Pcs M12-1.5 Wheel Studs Compatible with Honda CR-V Civic Accord City Element Prelude S2000 Acura TL TLX TSX EL CL CSX RSX ILXVigor Integra
  • 【Vehicle Fitment】 Compatible with Acura Integra 1986-1989; Compatible with Honda Civic 2004-2005, Element 2007-2010---Front Side; Compatible with Acura CL 1997-1999/2001-2003, RSX 2002-2006, TL 1995-2003, TLX 2015-2020, TSX 2009-2014, Vigor 1992-1994; Compatible with Honda Accord 1990-2002/2008-2015/2018-2021, Civic 2004-2005, CR-V 1997-2006, Element 2003-2011, HR-V 2016-2021, Prelude 1992-2001---Rear Side
  • 【Vehicle Fitment】 Compatible with Acura CSX 2006-2011, EL 1997-2005, ILX 2013-2021, Integra 1990-2001, TL/TSX 2004-2008; Compatible with Honda Accord 1982-1989/2003-2007, City 2010-2016, Civic 1980-2021, Civic del Sol 1993-1997, CRX 1988-1991, CR-Z 2011-2016, Fit 2006-2020, Insight 2000-2006/2010-2014/2019-2021, Prelude 1983-1991, S2000 2000-2009, Wagovan 1984/1986-1987---Front or Rear
  • 【Specifications】 Length: 22.23 mm; Thread Size: M12-1.50; Fitment: Direct Replacement
  • 【Firm Structure】 This studs are made of solid steel, and enable withstand horizontal vibration without breaking
  • 【Part Number】 610-269, 6102691, 90113S5H005, 90113SA0003, 90113SA0005, 90113SA0006, 90113SA0013, 90113SA0015, 90113SA0023, 90113SA0025, 90113SA0113, 90113SD2008, 90113SEPA01, 90113SM1005, 90113SM1025, 90113SM1055, 98436, 984361
Bestseller No. 9
A-Premium 10Pcs M12-1.5 Wheel Studs Compatible with Toyota Camry RAV4 Corolla Prius Highlander Sienna Avalon Chevrolet Prizm Nova Lexus ES300 ES330 ES350
  • 【Vehicle Fitment】 Compatible with Lexus ES300; Compatible with Scion xA/xB; Compatible with Toyota Avalon/Camry/Celica/Corolla/Echo/Previa/Prius/Sienna/Solara---Front Side; Compatible with Chevrolet Prizm/Nova; Compatible with Geo Prizm; Compatible with Lexus CT200h/ES300/ES300h/ES330/GS300/ES350/GS350/GS400/GS430/HS250h/IS F---Front or Rear
  • 【Vehicle Fitment】 Compatible with Lexus IS200t/IS250/IS300/IS350/LS400/LS430/NX200t/RC200t/RC300/RC350/RX300/RX330/RX350/RX400h/RX450h/SC300/SC400/SC430; Compatible with Pontiac Vibe; Compatible with Scion iM/tC/xB/xD; Compatible with Toyota Avalon/C-HR/Camry/Celica/Corolla/Corolla iM/Highlander/Matrix/MR2/Pickup/Prius/Prius C/Prius Prime/Prius V/RAV4/Sienna/Solara/Supra/Venza/Yaris---Front or Rear
  • 【Specifications】 Length: 31.877 mm; Thread Size: M12-1.50; Fitment: Direct Replacement
  • 【Firm Structure】 This studs are made of solid steel, and enable withstand horizontal vibration without breaking
  • 【Part Number】 610266, 610266.1, 610266.40, 610-266, 610-266.1, 610-266.40, 98485.1, 9094202049, 90942-02049, 9094202017, 90942-02017, 90942-02037, 9094202037, 9094202067, 90942-02070, 9094202082, 9094202070, 90942-02082, 94851865
Bestseller No. 10
Mysttoo M12x1.25 Wheel Hub Bolt Lug Stud Nut Set Compatible with 2002-2022 Subaru Forester Crosstrek Outback WRX STI Legacy Impreza BRZ Tribeca 28365FE001 28171AJ000 (4PCS)
  • COMPATIBILITY - Compatible with Subaru vehicles including Crosstrek WRX BRZ Forester Outback Legacy Ascent and others, strictly tested prior to market release, ensuring perfect application.
  • MATERIAL - Constructed of high-quality 10.9 grade steel, manufactured with heat treated steel for protection against rust and corrosion.
  • SPECIFICATION - Wheel Lug Nut M12 x1.25mm Thread - Stud Overall Length: 48mm.
  • REPLACES - Factory Part Number 28171AJ000, 28365FE001, 28171AG000.
  • 2 Years Quality Guarantee - We extremely value your satisfaction and strive to provide you good shopping experience. Any further question, please feel free to contact us at any time!

Last update on 2024-03-22 / Affiliate links / Images from Amazon Product Advertising API

This product presentation was made with AAWP plugin.

Leave a Comment

Share to...
