MIL Illumination Diagnostic Trouble Code P0339 – Crankshaft Position Sensor Intermittent Set – 2008-2010 Chrysler & Dodge

“This site contains affiliate links for which OEMDTC may be compensated”

NUMBER: 18-005-11
GROUP: Vehicle Performance
DATE: February 11, 2011



THIS BULLETIN SUPERSEDES SERVICE BULLETIN 18-024-10, DATED AUGUST 10, 2010, FOR LX/LC/LE/L2 VEHICLES ONLY WHICH SHOULD BE REMOVED FROM YOUR FILES. THIS IS A COMPLETE REVISION AND NO ASTERISKS HAVE BEEN USED TO HIGHLIGHT REVISIONS.

THIS SERVICE BULLETIN IS ALSO BEING RELEASED AS RAPID RESPONSE TRANSMITTAL 11-008 FOR 2010 LX 3.5L ENGINES ONLY. ALL APPLICABLE UN-SOLD VIN’s HAVE BEEN LOADED. TO VERIFY THAT THIS SERVICE ACTION IS APPLICABLE TO THE VEHICLE, USE VIP OR PERFORM A VIN SEARCH IN TECHCONNECT. APPLICATION OF THIS SERVICE BULLETIN TO SOLD UNITS IS BASED UPON THE CUSTOMER EXPERIENCING THE SYMPTOM/CONDITIONS. ALL REPAIRS ARE REIMBURSABLE WITHIN THE PROVISIONS OF WARRANTY.

HELP USING THE wiTECH DIAGNOSTIC APPLICATION FOR FLASHING AN ECU IS AVAILABLE BY SELECTING “HELP” THEN “HELP CONTENTS” AT THE TOP OF THE wiTECH DIAGNOSTIC APPLICATION WINDOW.

THE wiTECH SOFTWARE LEVEL MUST BE AT RELEASE 11.02 OR HIGHER TO PERFORM THIS PROCEDURE.



SUBJECT:

MIL Illumination Diagnostic Trouble Code P0339 – Crankshaft Position Sensor Intermittent Set



OVERVIEW:

This bulletin involves flash reprogramming the Powertrain Control Module (PCM) on certain vehicles and then verifying the condition has been corrected. If necessary your next step will be to add a shim to the crank sensor then verifying the condition has been corrected and only if necessary, replacing the flexplate.

There are two repair procedures for this service bulletin. One procedure is for un-sold 2010 LX 3.5L engines and a 4 speed transmission with NAA or NAE Emission. The second procedure is for all sold units.



MODELS:

2009 – 2010 (LC) Challenger
2008 – 2010 (LX) 300 / Magnum / Charger
2008 – 2010 (LE) 300C/300 Touring (International Markets)
2008 – 2009 (L2) 300 (China)



NOTE: This bulletin applies to models equipped with a 2.7L, 3.5L engines (sales code EER, EGG) and a automatic transmission.



SYMPTOM/CONDITION:

Some customers may complain of MIL illumination. No other symptoms will be noted or experienced. Further investigation by the technician may find DTC P0339 – Crankshaft Position Sensor Intermittent is set. It is possible that DTC’s P0300 – Multiple Cylinder Misfire and/or P1128 – Closed Loop Fueling Not Achieved – Bank 1 and/or P1129 – Closed Loop Fueling Not Achieved – Bank 2 could be set along with P0339 – Crankshaft Position Sensor Intermittent is set.

NOTE: P0339 – Crankshaft Position Sensor Intermittent must be set along with the other DTC’s listed above. If P0339 – Crankshaft Position Sensor Intermittent is not set then this bulletin does not apply.



DIAGNOSIS:

Using a Scan Tool (wiTech) with the appropriate Diagnostic Procedures available in TechCONNECT, verify all engine systems are functioning as designed. If DTC’s other than P0339 with or without P0300, P1128, P1129 are present then record them on the repair order and repair other DTC’s first as necessary before proceeding further with this bulletin.



PARTS REQUIRED:

Qty. Part No. Description
AR (1) 68061031AA MIL Illumination Diagnostic Trouble Code P0339 - Crankshaft Position Sensor Intermittent Set - 2008-2010 Chrysler & Dodge | small light Washer .022 (.56mm)
AR (1) 04736299AC MIL Illumination Diagnostic Trouble Code P0339 - Crankshaft Position Sensor Intermittent Set - 2008-2010 Chrysler & Dodge | small light Flexplate
(1) AR 04275086AB Label, Authorized Modification



SPECIAL TOOLS / EQUIPMENT REQUIRED:

NPN Battery Charger
NPN wiTECH



REPAIR PROCEDURE 2010 LX 3.5L with a 4 speed transmission and NAA or NAE Emissions Un-sold Units:

  1. Reprogram the PCM with the latest software. Help using the wiTECH diagnostic application for flashing an ECU is available by selecting “Help” then “Help Contents” at the top of the wiTECH diagnostic application window. After PCM reprogramming, the following must be performed:
    1. Clear any DTC’s that may have been set in other modules due to reprogramming. The wiTECH application will automatically present all DTCs after the flash and allow the tech to clear them.
    2. From the home screen of wiTECH select PCM.
    3. From the PCM Menu, Select the “Misc Functions” Tab.
    4. Perform a “ECU Reset” with wiTECH.
    5. Perform a “Cam/Crank Relearn” with wiTECH.
  1. Type the necessary information on the “Authorized Modification Label” and attach it near the VECI label and return vehicle to inventory.



REPAIR PROCEDURE all Sold Units:

  1. Is the vehicle a 2010 or 2009 LX 3.5L with a 4 speed transmission and NAA or NAE Emmissions?
    1. Yes >>> proceed to Step #3
    2. No >>> proceed to Step #2
  2. Is the vehicle a 2009 LC 3.5L with a 4 speed transmission and NAA or NAE Emmissions?
    1. Yes >>> proceed to Step #3
    2. No >>> proceed to Step #11
  3. Reprogram the PCM with the latest software. Help using the wiTECH diagnostic application for flashing an ECU is available by selecting “Help”then “Help Contents” at the top of the wiTECH diagnostic application window. After PCM reprogramming, the following must be performed:
    1. Clear any DTC’s that may have been set in other modules due to reprogramming.The wiTECH application will automatically present all DTCs after the flash and allow the tech to clear them.
    2. From the home screen of wiTECH select PCM.
    3. From the PCM Menu, Select the “Misc Functions” Tab.
    4. Perform a “ECU Reset” with wiTECH.
    5. Perform a “Cam/Crank Relearn” with wiTECH.
  4. Drive vehicle and perform 6 to 8 wide open throttle 1-2 shifts in the 5,800 RPM range.
  5. Connect wiTECH to vehicle.
  6. Select PCM.
  7. Select the “Monitor List” tab.
  8. Scroll down and select the “Cam Crank Synchronization Event Monitor”
  9. Scroll down and read both the “Engine Unlock Position” and the “Unlock RPM” status.
  10. Is the “Engine Unlock Position” between 40 and 55 or 400 and 415 degrees with the“Unlock RPM” greater than 3000 RPM?? a. Yes >>> proceed to Step #18
  11. No >>> Perform a “ECU Reset” with wiTECH and “Cam/Crank Relearn” with wiTECH.Repair Complete.
  12. Connect wiTECH to vehicle if not connected.
  13. Select PCM.
  14. Select the “Monitor List” tab.
  15. Scroll down and select the “Cam Crank Synchronization Event Monitor”
  16. Scroll down and read both the “Engine Unlock Position” and the “Unlock RPM” status.
  17. Is the “Engine Unlock Position” between 40 and 55 or 400 and 415 degrees?
    1. Yes >>> proceed to Step #17
    2. No >>> This Bulletin does not apply. Refer to the Diagnostic Procedure available in DealerCONNECT/TechCONNECT for P0339 – Crankshaft Position Sensor Intermittent to diagnose this condition.
  18. Is the “Unlock RPM” greater than 3000 rpm?
    1. Yes >>> proceed to Step #18
    2. No >>> Refer to the Diagnostic Procedure available in DealerCONNECT/TechCONNECT for P0339 – Crankshaft Position Sensor Intermittent to diagnose this condition.
  1. Remove the crankshaft position sensor. Follow the detailed service procedures available in DealerCONNECT/TECHCONNECT, Refer to 14 – Fuel System / Fuel Injection / SENSOR, Crankshaft Position / Removal.
  2. Install washer (p/n 68061031aa) between sensor fastener bushing and transmission.
  3. Reinstall the crankshaft position sensor.
  4. From the home screen of wiTECH select PCM.
  5. From the PCM Menu, Select the “Misc Functions” Tab.
  6. Perform a “ECU Reset” with wiTECH.
  7. Perform a “Cam/Crank Relearn” with wiTECH..

NOTE: It is necessary to perform a “ECU Reset and Cam/Crank Relearn” prior to driving the vehicle. If this step is not preformed the values will not be accurate. The values need to be reset.

  1. Drive vehicle and perform 6 to 8 wide open throttle 1-2 shifts in the 5,800 RPM range.
  2. Connect wiTECH to vehicle.
  3. Select PCM.
  4. Select the “Monitor List” tab.
  5. Scroll down and select the “Cam Crank Synchronization Event Monitor”
  6. Scroll down and read both the “Engine Unlock Position” and the “Unlock RPM” status.
  7. Is the “Engine Unlock Position” between 40 and 55 or 400 and 415 degrees with the“Unlock RPM” greater than 3000 RPM??
    1. Yes >>> proceed to Step #32
    2. No >>> Repair Complete.
  8. Replace flexplate. Refer to 09 – Engine, 3.5L or 2.7L / Engine Block / FLEXPLATE /Removal and Installation.
  9. From the home screen of wiTECH select PCM.
  10. From the PCM Menu, Select the “Misc Functions” Tab.
  11. Perform a “ECU Reset” with wiTECH.
  12. Perform a “Cam/Crank Relearn” with wiTECH..

NOTE: It is necessary to perform a “ECU Reset and Cam/Crank Relearn” prior to driving the vehicle. If this step is not preformed the values will not be accurate. The values need to be reset.

  1. Relearn ETC if necessary.
  2. Re-initalize power windows (LC models only).
  3. Type the necessary information on the “Authorized Modification Label” and attach itnear the VECI label and return vehicle to inventory.



POLICY:

Reimbursable within the provisions of the warranty.



TIME ALLOWANCE:

Labor Operation No: Description Amount
18-19-06-J1 Reprogram, Module Powertrain Control 2010 Un-Sold units (B) 0.2 Hrs.
18-19-06-J2 Reprogram, Module Powertrain Control 2010 or 2009 Sold units (B) 0.2 Hrs.
08-15-80-98 Check Cam Crank Synchronization Event Monitor 0.2 Hrs.
08-15-80-99 Monitor Events And Shim, Crankshaft Position Sensor (B) 0.6 Hrs.
08-15-80-9A Monitor Events, Shim ,Crankshaft Position sensor and Replace flexplate with 41TE or 42RLE transmission (B) 4.2 Hrs.
LX/LE/L2
Bodies
3.9 Hrs. LC
Body
08-15-80-9B Monitor Events, Shim ,Crankshaft Position sensor and Replace flexplate with NAG1 Transmission (B) 3.9 Hrs.



FAILURE CODE:

ZZ Service Action



Loader Loading...
EAD Logo Taking too long?

Reload Reload document
| Open Open in new tab

Download






Chrysler J2534 Application Overview

The Chrysler J2534 System is a combination of the J2534 Application (2010 and newer Model Year Support) and the Chrysler J2534 Flash Application (2009-1996 Model Year Support). J2534 aftermarket users are required and responsible for installing the J2534 device driver provided by the device manufacturer. If you need support installing the device driver software contact the device manufacturer. See the related article “Chrysler J2534 Manual” for additional information. Chrysler J2534 application provides below capabilities:



New J2534 Application:
New J2534 Application Application Usage and Support
  • Provides support for 2010 and newer model years.
  • New J2534 Application requires users to work online. An active internet connection and bandwidth (1.5 Mbps) is required to use J2534 application.
  • ECU reprogramming files are automatically downloaded via the application.
  • J2534 Applicable ECUs can be reprogrammed, if a flash is available.



The Chrysler J2534 Flash Application:
The Chrysler J2534 Flash Application Application Usage and Support
  • Provides support for 2009 – 1996 model years.
  • ECU reprogramming support for emission control modules only (ECM, PCM, TCM and CTV).



Chrysler Recommended J2534 Devices

For Chrysler recommended J2534 device, see below table.

J2534 Device MIL Illumination Diagnostic Trouble Code P0339 - Crankshaft Position Sensor Intermittent Set - 2008-2010 Chrysler & Dodge | small light MIL Illumination Diagnostic Trouble Code P0339 - Crankshaft Position Sensor Intermittent Set - 2008-2010 Chrysler & Dodge | small light Firmware Version
CTC Vehicle Box * 1.9
UCAN 2 1.0
Blue Streak -2534 Global Programmer 2.10
Actia I+ME Passthru 2.07



* Chrysler recommends the CTC Vehicle Box Device for Chrysler SCI ECU reprogramming. SCI reprogramming is used on most PCMs and TCMs prior to the introduction of CAN bus vehicles which began in 2004 (Durango).



Chrysler J2534 System Support:

Support for Chrysler J2534 System is available on-line. For more information, please refer to Chrysler J2534 Manual and knowledge base website.



Chrysler J2534 System

PC Requirements for Chrysler J2434 System:

The Chrysler J2534 Application has been verified to work with the following operating systems using open platform PCs or laptops:
• Windows 7 (32-Bit & 64-Bit)
• Windows XP (32-Bit only)


Chrysler J2434 System Release Notes:

Please click here to view the Application Release Notes.


Chrysler J2434 System Download:

For Chrysler J2534 System support, please refer to “Chrysler J2534 Manual“. Get the J2534 system.


Chrysler ECU Flash Availability matrix:

Click Flash Availability–J2534 Application and Flash Availability–Chrysler Diagnostic Application.


Adaptor Requirements:

A harness adaptor is required to update certain vehicles. The following tables list which vehicles / modules require which adaptor. Adaptors can be purchased through the SPX Miller Special Tools program.  See SPX Miller Special Tools program for details.

MLR-J2534-MMC required on:

SBEC III 1996 – 1997 SEBRING / AVENGER (FJ)
ETAX III 1996 – 1997 SEBRING / AVENGER (FJ)
SBEC IIIA 1997 – 1998 SEBRING / AVENGER (FJ)
ETAX IIIA 1997 – 1998 SEBRING / AVENGER (FJ)
Powertrain 2001 – 2201 SEBRING / STRATUS COUPE (ST)



MLR-J2534-TCM required on:

ETAX IIIB 2003 – 2004 SEBRING / STRATUS SEDAN (JR)
ETAX IVA 2005 – 2006 LIBERTY (DIESEL) JEEP (KJ)




Additional Information and Known Issues / Concerns:

If you are reprogramming the 5.9L diesel engine controller on the 1996-2008 Dodge RAM vehicle, it is necessary to also reprogram the VIN after the ECU has been flashed.  To write the VIN to the ECU, you may use aftermarket software support, or use an OEM FCA US LLC scan tool (DRBIII or StarSCAN). For more information, see the FCA US LLC Scan Tool Lease Options section.

  • 1996-2009 ALL PCMs

If you are REPLACING a PCM or ECM and the vehicle is equipped with a theft deterrent system (Sentry Key), it must be initialized to properly function with the Anti Theft module. You also need to reprogram the VIN when replacing a PCM or ECM.  To write the VIN to the ECU and initialize the PCM to work with the theft deterrent system, you may use aftermarket software support, or use an OEM FCA US LLC scan tool (DRBIII or StarSCAN). For more information, see the FCA US LLC Scan Tool Lease Options section.


FCA US LLC Scan Tool Lease Options:

  • For 2009 model year vehicles and prior, it may be necessary to use either a DRBIII or a StarSCAN to perform function required after ECU replacement.  To lease the DRBIII call 1-586-532-8400 or click here.
  • Beginning with 2010 MY, function required to replace an ECU will be supported via the J2534 application.
